SPECIFICATIONS
T6M SERIES MOBILE SERVICE MANUAL – SM/16/1.0 Page 2-1
2. T6M Series Specifications
The following specifications are intended for testing and servicing the mobile
radio. Specifications are subject to change without notice.
2.1 General
Air Interface None
Operating Mode Single Frequency Simplex
Frequency Range
Receive 118 - 137 MHz
Transmit 118 - 137 MHz
Channel Bandwidth 25 kHz and 8.33 kHz.
Channel Increment 8.33 kHz
Input Voltage 13.2 VDC nominal (10.8 V to 18 V),
negative ground
Max Receive Current 2A
Max Off Current 100mA
Audio Output 4W into 4ohm external speaker
(<10%THD)
Temperature Range
Normal +15°C to +35°C
Operating -20°C to +55°C
Storage -40°C to +85°C
Dimensions
Width 177 mm (6.95”)
Depth 228 mm (8.98”)
Height 50 mm (1.95”)
Weight 1.75 kg (±0.1kg)
Approvals CE, SERPS, MOPS
EN300 279 Ed 2
EN 300 676
2.2 Receiver
Sensitivity -100dBm
Selectivity 50dB @ 8.33kHz, 60dB @ 25kHz
Intermodulation 60dB
Spurious and Image Rejection 75dB
Audio Power Output 4 Watts.
Distortion <10% THD
RF Input Impedance 50 ohms
