Page #7 background imageLoading...
Page #7 background image
4
LED Definition
LED indicators for the device
Feature
Description
PWR LED
The switch is powered by the external
power adapter (DC 48V).
PD LED
The switch is powered by the PD port.
(high-power 60W).
PoE LED
It indicates the PoE connection status of
the port 1 to port 4. A steady green LED
indicates that a valid PD device is
connecting to the PoE port, while a
blinking LED indicates no valid PD
device been connected to the PoE port.
LNK/ACT
LED
- Steady green: Valid port connection.
- Blinking green: Valid port connection
and there is data transmitting/ receiving.
- Off: Port disconnected.
The Rear Panel
There are a DC jack for external power adapter
(optional) and 8 Ethernet ports for local switching on the
