5
rear panel. All Ethernet ports feature 10/100/1000 Mbps
with auto-negotiation and auto MDI-X.
The rear panel of the switch is shown as below:
The rear panel port description
Feature
Description
Power
DC 48V
The DC 48V power adapter is optional if
local network could supply power to PD
port
Uplink /PD
10/100/1000Mbps Ethernet ports
feature with auto-negotiation and auto
MDI-X also could receive power from
Ethernet cable (high-power support).
Port 1~4
w/ PoE
10/100/1000Mbps Ethernet ports
feature with auto-negotiation and auto
MDI-X also with power supply provide
(IEEE 802.3af support).
Port 5~7
10/100/1000Mbps Ethernet ports
feature with auto-negotiation and auto
MDI-X.
Power could be provided on port 1~4 if there is sufficient
power available on the system.
This switch can power these combinations of devices:
 Three class 0,3 PD device (3x15W) or
 Four class 1 PD devices (4x4W) or
