13. Lubrication

Usually it is not necessary to lubricate the actuator as all moving parts are lubricated for life;

however, in the unlikely event that additional lubrication is required, the following lubricant

should be used:

Manufacturer AGIP

Trade Name AGIP GR MU EP

Colour Yellow/Brown

Oil Type Mineral

Consistency (NLGI Grade) – ASTM D217 1

Worked Penetration at 25°C – ASTM D217 325 dmm

Dropping Point ASTM D2265 185°C

Viscosity of Base Oil at 40°C – ASTM D445 160 mm2/s

14. Replacement Seal Kits

When undertaking any service work, it is strongly recommended that all seals removed during

disassembly be replaced. Please refer to the below tables when ordering replacement seal kits:

14.1 Pneumatic Cylinder Spares Kits

Pneumatic cylinder spares kits comprise of the following items:

 Piston Sliding Ring (1 off with 1 off enclosed O-ring)

 Piston Rod Sliding Ring (1 off with 1 off enclosed O-ring)

 Flange O-ring (2 off)

 Piston Rod O-ring (1 off)

 End Stop O-ring (1 off)

For more information regarding the above items, please see Section 16.3, Dwg. PNX-

XXX-CYXXX-00-001-PL.

14.2 Frame Spares Kits

Frame spares kits comprise of the following items:

 Yoke O-Ring (2 off)

 Guide Bar O-Ring (2 off)

 Plug O-Ring (1 off)

 Bushing O-Ring (2 off)

For more information regarding the above items, please see Section 16.1, Dwg. XXX-

XXX-FRXXX-00-001-PL.

NOTE: Each seal kit includes a tube of silicone to replace any paste gaskets

seals broken during maintenance.
