Pall Palltronic Flow Check II User Manual

3. Using the Palltronic Flow Check II Unit
3
.1 Features
The Palltronic Flow Check II unit provides two pneumatic ports, as follows:
Figure 1
The specification label attached to the enclosure displays the certified flow rate using air at an
atmospheric pressure of 1000 mbar (14.5 psi), the associated test pressure and the unit serial
number.
The display is switched on by pressing the button on the right hand side:
Figure 2
www.pall.com/biopharm 5
1 = ‘Start’ Button
2 = Display
1 = Specification label
2 = ‘IN’ port
3 = ‘Vent’ port
2
2
3
1
1

Pall Palltronic Flow Check II Specifications

General

Brand	Pall
Model	Palltronic Flow Check II
Category	Test Equipment
Language	English
