PalmSens EmStat3+ User Manual

Getting started with the EmStat3+ module for OEM 8
Getting started with the EmStat3+ module for OEM
2.3 Pinout of sensor plug
See CON4 on page 5.
Front view of socket
Solder side of socket
1 ● ● 4
2 ● ● 3
4 ● ● 1
3 ● ● 2
1. RE: blue connector or reference electrode
2. CE: black connector or counter electrode
3. S: red female/male connector or sense
4. WE: red connector is working electrode
The shield of the cable must make contact with the metal case of the
sensor connector or AGND.
