Panasonic 5300U

23
■
Using the Rear Support Strap

■
Using the Rubber Cushion (option)
(If there is an existing Rear Support Bracket on the fire wall of the vehicle.)
Cover Mounting Bolt on the rear of the unit with Rubber Cushion (option), and mount it into the
existing Rear Support Bracket.
Rubber Cushion (option)
Mounting Bolt
Mounting Collar
Rear Support Bracket
(existing on the vehicle)
Installation Guide
(continued)
3. After installation reconnect the negative (–) battery terminal.
