Panasonic 6298 - Installation and Wiring Procedures; Common Installation Guide

6295-6298 ENCLOSED HEAT DETECTOR
- FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION
8
5. INSTALLATION AND WIRING
5.1. COMMON INSTALLATION (6295-6298)
Screen wire termination is not provided.
6295-62986295-6298
End-of-line device
Wire size (Min) Ø 0.6 mm (0.3 mm²)
Wire size (Max) Ø 1.2 mm (1.13 mm²)
C.i.e.
E+ E- B-
A+
A+ B- E+ E-
