Panasonic AG-CVF10G - Detaching the Eyepiece and Performing Maintenance

E-13
Itiseasiertoseethewholescreeniftheeyepieceisdetachedattimeswhenyouwanttolookuporaway
fromtheviewnderandtakeshots.
Also,detachtheeyepieceifthereisanydirtonthemirrorsothatthedirtcanberemoved.
Note
Whenthereisanydirtonthemirror,blowitawaywithablower,etc.
Ifanydirtisstillleft,wipeitawayusingasoftcloth.
1Turnthelockringasfarasitwillgoin
thecounterclockwisedirectionasseen
fromtheeyepieceside,andlineupthe
alignmentmarksonthelockringand
viewnderbarrel.
Alignment marks
Eyepiece
Lock ring
2Detachtheeyepiece.
Remounting the eyepiece
1Lineupthealignmentmarksonthe
lockringandtheviewnderbarreland
slidetheeyepiecebackintoplace.
2Turnthelockringclockwiseasfaras
the
position.
Notes
•Donotleavetheeyepieceoutdoorspointingatthesun.Heatfromthesunlightmaydamagethe
partsinside.
•Takecarenottoloseormisplacetheeyepieceafterithasbeenremoved.
Detaching the eyepiece and performing maintenance
