Panasonic Aquarea WH-ADC0309J3E5C - Tank

215
Aquarea air-to-water heat pumps - Planning and installation manual - 02/2022
Appendix
8
32
Menus
For installer
Menu Default Setting Setting Options / Display
Water temp. for cooling ON Direct
10 °C
Set temperature for
Cooling ON
•If 2 zone system is selected, temperature set point must input for Zone 2�
•“Zone 1” and “Zone 2” will not appear on the display if only 1 zone system�
T for cooling ON
5 °C
Set
T for cooling ON
* This setting will not
available to set when
pump owrate set to
Max� duty�
6.3
*
1,
*
2
Auto
Automatic switch from Heat to
Cool or Cool to Heat�
Outdoor temperatures for switching from Heat
to Cool or Cool to Heat�
Outdoor temp� for (Heat to Cool) /
Outdoor temp� for (Cool to Heat)
Outdoor temp. for (Heat to Cool)
15 °C
Set outdoor
temperature for
switching
from Heat to Cool�
Outdoor temp. for (Cool to Heat)
10 °C
Set outdoor
temperature for
switching
from Cool to Heat�
6.4
Tank
Setting functions for the tank�
Floor operation time (max) /
Tank heat up time (max) /
Tank re-heat temp� /
Sterilization
•The display will show 3 functions at a time�
Floor operation time (max)
8:00
Maximum time for
oor operation
(in hours and minutes)
*
1
The system is locked to operate without COOL mode� It can be unlocked only by authorised installers or our authorised service partners�
*
2
Only displayed when COOL mode is unlocked (This means when COOL mode is available)�
