35
SDI outputs HD‑SDI: HD Serial digital (SMPTE 292M)
SD‑SDI: SD Serial digital (SMPTE 259M)
5 signal lines, standard: OUT1 2; OUT2 to OUT5 1 each
9 signal lines, maximum: OUT A1, OUT A2, OUT B1, OUT B2
(When two AV‑HS04M7 boards are used)
HD: SMPTE 292M (BTA S‑004B) standard complied with
• Output level 0.8 V [p‑p] 10 %
• Rise time HD: Less than 270 ps
• Fall time HD: Less than 270 ps
• Difference between rise time and fall time
HD: Less than 100 ps
• Alignment jitter HD: Less than 0.2 UI (130 ps)
• Timing jitter HD: Less than 1.0 UI
• Eye aperture ratio More than 90 %
• DC offset 0 0.5 V
SD: SMPTE 259M standard complied with
• Output level 0.8 V [p‑p] 10 %
• Rise time Less than 1.5 ns
• Fall time Less than 1.5 ns
• Difference between rise time and fall time
Less than 0.5 ns
• Jitter Less than 0.2 UI
Composite input
(Option board)
Analog composite signal (NTSC/PAL) (1.0 V [p‑p], 75 )
4 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV‑HS04M6 boards are used; with loop‑through)
Analog input
(Option board)
SD/HD analog component Y/P
B/PR (1.0 V [p‑p], 75 )
4 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV‑HS04M2 boards are used)
Analog output
(Option board)
SD/HD analog component Y/P
B/PR (1.0 V [p‑p], 75 )
4 signal lines, maximum: OUT A1, OUT A2, OUT B1, OUT B2
(When two AV‑HS04M4 boards are used)
p 2 signal lines (OUT A1, OUT B1) when two AV‑HS04M5 boards are used.
DVI-I input
(Option board)
Analog/digital RGB:
XGA (1024768), WXGA (1280768), SXGA (12801024)
Vertical frequency: 60 Hz
p This connector does not support the HDCP technologies.
4 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV‑HS04M3 boards are used)
DVI-I output
(Option board)
Analog/digital RGB:
XGA (1024768), WXGA (1280768), SXGA (12801024),
WSXGA+* (16801050), UXGA* (16001200), WUXGA* (19201200)
*: Selectable only when digital signals are output.
Vertical frequency: 60 Hz
p This connector does not support the HDCP technologies.
2 signal lines, maximum: OUT A2, OUT B2
(When two AV‑HS04M5 boards are used)
DVI-D input
(Option board)
Digital RGB:
XGA (1024768), WXGA (1280768), SXGA (12801024), WSXGA+ (16801050),
UXGA (16001200), WUXGA (19201200)
Vertical frequency: 60 Hz
Digital RGB: 1080/50p, 1080/59.94p
p Analog input signals are not supported.
p This connector does not support the HDCP technologies.
4 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV‑HS04M8 boards are used)
p The DVI‑I connector cable cannot be used.
p For the DVI‑D connector cable, use a cable with a length of up to 5 m (16.4 ft).
4. Specifications
