4. Specifications
Power supply: AC 100 V to 240 V, 50/60 Hz
Power consumption: 88 W
indicates safety information.
Video inputs
(13 signal lines, maximum)
Standard SDI: 8 signal lines (SDI INPUT 1 to SDI INPUT 8)
p The up‑converter function can be used for the SDI INPUT 5 to
SDI INPUT 8 connectors.
BNC 8
Standard DVI‑D: 1 signal line
DVI‑D 1
Optional: Up to 4 additional signal lines (IN A1, IN A2, IN B1, IN B2)
(Up to two option boards can be installed in the two input/output slots.)
Video outputs
(10 signal lines, maximum)
Standard SDI:
5 signal lines (SDI OUTPUT 1 to SDI OUTPUT 5 1 line each,
2 distributed outputs for SDI OUTPUT 1 only)
BNC 6
Standard DVI‑D: 1 signal line
DVI‑D 1
Optional: Up to 4 additional lines (OUT A1, OUT A2, OUT B1, OUT B2)
(Up to two option boards can be installed in the two input/output slots.)
p PGM, PVW, AUX1 to AUX4, MV (MULTI_VIEW), CLN, KEYOUT and MEM PVW can be
assigned to SDI OUTPUT 1 to SDI OUTPUT 5, DVI‑D OUT, OUT A1, OUT A2, OUT B1 and
OUT B2.
p CLN can be pre‑selected from KEY or DSK using a menu.
Signal formats SD 480/59.94i, 576/50i
HD 1080/59.94i, 1080/50i, 720/59.94p, 720/50p, 1080/24PsF*, 1080/23.98PsF*
*: The following option boards are not supported:
AV‑HS04M1, AV‑HS04M2, AV‑HS04M3, AV‑HS04M4, AV‑HS04M5,
AV‑HS04M6, AV‑HS04M7
Signal processing Y:PB:PR 4: 2: 2, 10 bit (8 bits for video memory)
RGB 4:4:4, 8 bit
ME number 1ME
SDI inputs HD‑SDI: HD Serial digital (SMPTE 292M)
SD‑SDI: SD Serial digital (SMPTE 259M)
8 signal lines, standard: IN1 to IN8
12 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV‑HS04M1 boards are used; with active through)
HD: SMPTE 292M (BTA S‑004B) standard complied with
• 0.8 V [p‑p] 10 % (75 )
• Automatic equalizer More than 100 m (328 ft) (when 1.5 Gbps/5C‑FB cable is used)
SD: SMPTE 259M standard complied with
• 0.8 V [p‑p] 10 % (75 )
• Automatic equalizer 200 m (656 ft) (when 5C‑2V cable is used)
