Control I/O COM Used to control an external device
RS‑422 control connector
Communication format (selected using a menu)
p Mode: 1 (default setting)
Baud rate : 9600 bps
Character length : 8 bit
Parity : None
Stop bit : 1 bit
Flow control : None
p Mode: 2
Baud rate : 38400 bps
Character length : 8 bit
Parity : Odd
Stop bit : 1 bit
Flow control : None
p Mode: 3
Baud rate : 38400 bps
Character length : 8 bit
Parity : None
Stop bit : 1 bit
Flow control : None
D‑sub, 9‑pin, female
TALLY/GPI 1
TALLY/GPI 2
Input:
8 inputs, general‑purpose,
photocoupler sensing
Output:
19 outputs; selected from R/G tally,
general‑purpose
Alarm:
1 output, open collector output
(negative logic)
D‑sub, 15‑pin,
female (2)
Other BOOT switch [SV/NM (service/normal)] (for maintenance purposes)
Normally, this switch is used as the “NM” position.
Ambient operating
temperature
0 °C to 40 °C (32 °F to 104 °F)
Humidity 10 % to 90 % (no condensation)
Dimensions
(W H D)
440 mm 158 mm 361 mm (17‑5/16 inches 6‑7/32 inches 14‑7/32 inches)
[excluding protrusions]
Mass Approx. 6.2 kg (13.669 lb)
[excluding accessory parts when no options have been installed]
Approx. 6.6 kg (14.550 lb)
[excluding accessory parts when all the possible options have been installed]
4. Specifications
