10.6. CD PLAYER PARTS LIST
Notes :
1. Be sure to make your orders of replacement parts accord-
ing to this list.
2. Important safety notice: Components, identified by
mark have special characteristics important for safety.
When replacing any of these components, use only man-
ufacturer's specified parts.
3. Location keys in the remarks column indicates the gen-
eral location of the parts shown in the exploded drawing,
as in a road map.
4. The marking (RTL) indicates that Retention Time is lim-
ited for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability
is dependent on the type of assembly, and in accordance
with the laws governing part and product retention. After
the end of this period, the assembly will no longer be
available.
• Order intake period is basically six months after the first
shipment.
Ref. No. Part No. Part Name & Description Remarks
[3032-14-49] CD Servo Block
IC's and TRANSISTORs
IC101 YESAM383 IC
IC201 YESAM339 IC
Q101 YESAN086 Transistor
DIODEs
D103 YESAD177 Diode
CAPASITORs
C101 YESCC585 Ceramic, 0.1µF 50WV
C102 YESCC585 Ceramic, 0.1µF 50WV
C103 YESCC585 Ceramic, 0.1µF 50WV
C104 YESCC299 Ceramic, 0.022µF 50WV
C105 YESCC209 Ceramic, 0.0033µF 50WV
C106 YESCC383 Ceramic, 0.33µF 10WV
C107 YESCC585 Ceramic, 0.1µF 50WV
C108 YESCC382 Ceramic, 680pF 50WV
C109 YESCC586 Ceramic, 4.7uF 6.3WV
C110 YESCC585 Ceramic, 0.1µF 50WV
C111 YESCC207 Ceramic, 0.001µF 50WV
C112 YESCC587 Ceramic, 0.082µF 25WV
C113 YESCC383 Ceramic, 0.33µF 10WV
C114 YESCC207 Ceramic, 0.001µF 50WV
C115 YESCC585 Ceramic, 0.1µF 50WV
C116 YESCC585 Ceramic, 0.1µF 50WV
C117 YESCC585 Ceramic, 0.1µF 50WV
C118 YESCC585 Ceramic, 0.1µF 50WV
C119 YESCC585 Ceramic, 0.1µF 50WV
C120 YESCC298 Ceramic, 0.015µF 50WV
C121 YESCC585 Ceramic, 0.1µF 50WV
C122 YESCC585 Ceramic, 0.1µF 50WV
C124 YESCC185 Ceramic, 0.01µF 50WV
C127 YESCC585 Ceramic, 0.1µF 50WV
C128 YESCC585 Ceramic, 0.1µF 50WV
C151 YESCC459 Electrolytic, 47µF 6.3WV
C152 YESCC459 Electrolytic, 47µF 6.3WV
C153 YESCC391 Electrolytic, 100µF 16WV
C154 YESCC391 Electrolytic, 100µF 16WV
C156 YESCC459 Electrolytic, 47µF 6.3WV
C159 YESCC459 Electrolytic, 47µF 6.3WV
C160 YESCC459 Electrolytic, 47µF 6.3WV
C161 YESCC459 Electrolytic, 47µF 6.3WV
C163 YESCC381 Ceramic, 10uF 6.3WV
C164 YESCC452 Ceramic, 1µF 16WV
C165 YESCC532 Ceramic, 47pF 50WV
C166 YESCC532 Ceramic, 47pF 50WV
C167 YESCC532 Ceramic, 47pF 50WV
C201 YESCC299 Ceramic, 0.022µF 50WV
C202 YESCC504 Ceramic, 0.0068µF 50WV
C204 YESCC183 Ceramic, 0.0022µF 50WV
C205 YESCC591 Ceramic, 820pF 50WV
C206 YESCC585 Ceramic, 0.1µF 50WV
C251 YESCC390 Electrolytic, 220µF 10WV
C252 YESCC390 Electrolytic, 220µF 10WV
C301 YESCC203 Ceramic, 220pF 50WV
C302 YESCC203 Ceramic, 220pF 50WV
C303 YESCC185 Ceramic, 0.01µF 50WV
C304 YESCC185 Ceramic, 0.01µF 50WV
C305 YESCC381 Ceramic, 10uF 6.3WV
C306 YESCC381 Ceramic, 10uF 6.3WV
C307 YESCC382 Ceramic, 680pF 50WV
C308 YESCC382 Ceramic, 680pF 50WV
C309 YESCC585 Ceramic, 0.1µF 50WV
C351 YESCC391 Electrolytic, 100µF 16WV
C352 YESCC390 Electrolytic, 220µF 10WV
RESISTORs
R101 YESRG234 Chip, 4.7Ω 1/10W
R102 ERJ3GEY0R00V Chip, 0Ω 1/16W
R103 ERJ3GEY0R00V Chip, 0Ω 1/16W
R104 ERJ3GEY0R00V Chip, 0Ω 1/16W
R105 ERJ3GEY0R00V Chip, 0Ω 1/16W
R111 YESRG240 Chip, 82kΩ 1/10W
R112 YESRG239 Chip, 820Ω 1/10W
R113 YESRG457 Chip, 2.7kΩ 1/10W
R114 YESRG355 Chip, 1MΩ 1/10W
R115 YESRG221 Chip, 100Ω 1/10W
R117 YESRG223 Chip, 10kΩ 1/10W
R119 YESRG223 Chip, 10kΩ 1/10W
R120 YESRG230 Chip, 3.3kΩ 1/10W
R121 YESRG230 Chip, 3.3kΩ 1/10W
R122 YESRG232 Chip, 4.7kΩ 1/10W
R124 YESRG223 Chip, 10kΩ 1/10W
R125 YESRG228 Chip, 22kΩ 1/10W
R126 YESRG223 Chip, 10kΩ 1/10W
R127 YESRG223 Chip, 10kΩ 1/10W
R129 YESRG238 Chip, 56kΩ 1/10W
R135 YESRG231 Chip, 33kΩ 1/10W
R143 ERJ3GEY0R00V Chip, 0Ω 1/16W
R145 ERJ3GEY0R00V Chip, 0Ω 1/16W
R146 YESRG233 Chip, 47kΩ 1/10W
R147 YESRG226 Chip, 220Ω 1/10W
R148 YESRG221 Chip, 100Ω 1/10W
R149 YESRG221 Chip, 100Ω 1/10W
R150 YESRG221 Chip, 100Ω 1/10W
R151 YESRG221 Chip, 100Ω 1/10W
R152 YESRG221 Chip, 100Ω 1/10W
R156 ERJ3GEY0R00V Chip, 0Ω 1/16W
R158 ERJ3GEY0R00V Chip, 0Ω 1/16W
R159 ERJ3GEY0R00V Chip, 0Ω 1/16W
R162 ERJ3GEY0R00V Chip, 0Ω 1/16W
R166 YESRG223 Chip, 10kΩ 1/10W
R167 YESRG223 Chip, 10kΩ 1/10W
R168 ERJ3GEY0R00V Chip, 0Ω 1/16W
R170 ERJ3GEY0R00V Chip, 0Ω 1/16W
R172 ERJ3GEY0R00V Chip, 0Ω 1/16W
R201 YESRG228 Chip, 22kΩ 1/10W
R202 YESRG232 Chip, 4.7kΩ 1/10W
R204 YESRG356 Chip, 15kΩ 1/10W
R205 ERJ3GEY0R00V Chip, 0Ω 1/16W
R206 YESRG466 Chip, 8.2kΩ 1/10W
R207 YESRG228 Chip, 22kΩ 1/10W
R208 YESRG231 Chip, 33kΩ 1/10W
R209 YESRG318 Chip, 39kΩ 1/10W
R210 YESRG237 Chip, 5.6kΩ 1/10W
R211 YESRG237 Chip, 5.6kΩ 1/10W
Ref. No. Part No. Part Name & Description Remarks
