CQ-D1703W
8
Preparation
Warning
¡Keep batteries away from children to avoid the risk of
accidents. If an infant ingests a battery, please seek
immediate medical attention.
Caution
¡ Remove and dispose of an old battery immediately.
¡ Do not disassemble, heat or short a battery. Do not
throw a battery into a fire or water.
¡ Follow local regulations when disposing of a battery.
¡Improper use of a battery may cause overheating, an
explosion or ignition, resulting in injury or a fire.
Note:
¡Battery Information:
Battery Type: Panasonic lithium battery (CR2025)
Battery Life: Approximately 6 months under normal use
(at room temperature)
Remote Control Unit
Battery Replacement
q Remove the battery holder with
the remote control unit placed
on a flat surface.
q Stick your thumbnail into
the groove, and push the
holder in the direction of the
arrow at the same time.
w Pull it out in the direction of
the arrow using a tough
pointed object.
w Put a battery in the case with
(+) side facing up.
e Put the case back.
Tough pointed object
Back side
Main Unit
TV Type setting
You can select a TV standard format (NTSC/PAL). Refer to
“Optional system (Example)” (
a Page 7) and “TV Type”
(
a Page 32).
Clock Setting
The 24-hour system is used for the clock.
q Press[SRC/PWR] to turn on the power.
w Press [DISP] (CLOCK).
Clock display
[SRC/PWR] (Power)
[DISP] (CLOCK)
[
]][[]
(Hour/minute adjustment)
e Press and hold [DISP] (CLOCK) for more than 2 sec-
onds.
Hour blinks
r Adjust the hour.
[[]: put forward hour.
[]]: put back hour.
Hour entered
t Press [DISP] (CLOCK).
Minute blinks
y Adjust the minute.
[[]: put forward minute.
[]]: put back minute.
Minute entered
u Press [DISP] (CLOCK).
Completed
Note:
¡“ADJUST” is displayed before adjusting the clock.
¡Press and hold [[] or []] to change numbers rapidly.
To Next Page
