V. SPECIFICATIONS
MAIN UNIT
Model EY7411
Capacity
Screw driving
Machine screw M2.5 – M5
Wood screw ø 3.8 × 38 mm (5/32
"
× 1-29/64
"
)
Drilling For metal ø 5 mm (13/64
"
) spc t = 1.6 mm
Motor 3.6 V DC
No load speed
LOW: 200 min
-1
(rpm)
HIGH: 600 min
-1
(rpm)
Maximum torque
LOW: 4.4 N·m (45 kgf-cm, 39 in-lbs)
HIGH: 1.5 N·m (15 kgf-cm, 13 in-lbs)
Maximum clutch torque 3.0 N·m (30 kgf-cm, 26 in-lbs)
Overall length 283 mm (11-5/32
"
)
Weight (with battery pack) 0.5 kg (1.1 lbs)
BATTERY PACK
Model EY9L10
Storage battery Li-ion Battery
Battery voltage 3.6 V DC (3.6 V × 1 cell)
Capacity 1.5 Ah
BATTERY CHARGER
Model EY0L10
Weight 0.6 kg (1.3 lbs)
Electrical rating See the rating plate on the bottom of the charger.
Charging time
2.4 V
3.6 V
1.2 Ah
EY9021
Full: 15 min.
EY9025
Full: 15 min.
1.5 Ah
EY9L10
Usable: 15 min.
Full: 30 min.
NOTE:
• For applicable battery packs to this charger, see the label on the charger or the
latest general catalog.
The instruction label on the battery packs also shows the applicable charger.
