– 9 –
CS-A120TE
Relative Position Between The Indoor Unit And The Installation Parts
Dimensions
CS-A120T
CS-A180T
CS-A240T
70 80
150
95
650
220
210
180
32
65
132
165
46 15
157
1100
Drain outlet
Wireless remote-control
transmitter
<Installation on the Wall>
CeilingCeiling
<Installation on the Ceiling>
Relative position between the hole and the bracket
Wall
Centre-line for the
piping hole
Suspention
bolt
Installation
bracket
Floor
Floor mount
bracket
<Installation on the Floor>
for left rear
piping
for right rear
piping
Wall
Wall mount
bracket
Piping hole (ø70)Piping hole (ø70)
Untitled-10 6/19/00, 6:38 PM9
