Panasonic CS-A12BKP Service Manual

Note:
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”
L ; Half Union 1/4”
G ; 3-way valve 1/2”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire (1)
(2)
(4)
3 (1.0 mm
2
) —
(3) 3 (1.5 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 21 - 1/4 (540)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 8 - 9/32 (210) 11 - 3/8 (289)
Net Weight lb (kg) 20 (9.0) 82 (37.0)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 930
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 44.8 - 53.5 64.8 - 73.2
Rate Output W 15 33
Fan
Speed
Low rpm (1)
(2)
(4)
Cooling; 900 -900
Heating; 960 - 960
—
(3) Cooling; 900, Heating; 960 —
Medium rpm (1)
(2)
(4)
Cooling; 1,120 - 1,120
Heating; 1,120 - 1,120
—
(3) Cooling; 1,120, Heating; 1,120 —
High rpm (1)
(2)
(4)
Cooling; 1,260 - 1,260
Heating; 1,300 - 1,300
835 - 845
(3) Cooling; 1,260, Heating; 1,300 835 - 845
SuperHigh rpm (1)
(2)
(4)
Cooling; 1,300 - 1,300
Heating; 1,300 - 1,300
—
(3) Cooling; 1,300, Heating; 1,300 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugate Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 2×24
FPI 21 17
Size (W × H × L) mm 610 × 315 × 25.4 705.8
735.1
× 504 × 18.9
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — SUNISO 4GSI (410)
Refrigerant (R-22) g (oz) — 1,090 (38.5)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 630, Heating; 455
Flow Rate l/min — Cooling; 6.5, Heating; 13.6
Inner Diameter mm — Cooling; 1.2, Heating; 1.5
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
• Specifications are subject to change without notice for further improvement.
• (1) — CS-A12BKP/CU-A12BKP5 (Europe).
• (2) — CS-A12BKP-2/CU-A12BKP5-2 (Oceania).
• (3) — CS-A12BKP-3/CU-A12BKP5-3 (Argentina).
• (4) — CS-A12BKP-6/CU-A12BKP5-6 (Turkey).
11
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6
