Panasonic CS-A12BKP

18 Replacement Parts List
<Model: CU-A7BK / CU-A9BK / CU-A12BK>
REF. NO. PART NAME & DESCRIPTION QTY. CU-A7BK CU-A9BK CU-A12BK REMARKS
1 CHASSY ASS’Y 1 CWD50K2045A
←
CWD50K2044A
2 SOUND PROOF MATERIAL 1 CWG302110
← ←
3 FAN MOTOR BRACKET 1 CWD541030
← ←
4 SCREW - FAN MOTOR BRACKET 2 CWH55413
← ←
5 FAN MOTOR 1 CWA951087
←
CWA951117 0
6 SCREW - FAN MOTOR MOUNT 3 CWH55406
← ←
7 PROPELLER FAN ASS’Y 1 CWH03K1006
← ←
8 NUT - PROPELLER FAN 1 CWH56053
← ←
9 COMPRESSOR 1 2RS122D5BC02 2PS156D3BA02 QJ208PAA 0
10 ANTI - VIBRATION BUSHING 3 CWH50077
←
CWH501024
11 NUT - COMPRESSOR MOUNT 3 CWH56000
←
CWH4582065
12 CONDENSER 1 CWB32C1113
←
CWB32C1112
13 4-WAY VALVE 1 CWB001012
←
CWB00003 0
14 STRAINER 1 CWB11025
← ←
15 HOLDER COUPLING ASS’Y 1 CWH351015
← ←
16 2-WAY VALVE (LIQUID) 1 CWB021055
← ←
0
17 3-WAY VALVE (GAS) 1 CWB011061
←
CWB011060 0
18 OVERLOAD PROTECTOR 1 CWA121050 CWA121051 CWA121060 0
19 HOLDER - O.L.P. 1 CWH7041200
←
-
20 TERMINAL COVER 1 CWH171011
←
CWH171021
21 NUT - TERMINAL COVER 1 CWH7080300
←
CWH561020
22 SOUND PROOF BOARD 1 CWH151022
←
CWH151023
23 CONTROL BOARD 1 CWH102102
← ←
24 TERMINAL BOARD ASS’Y 1 CWA28K216
← ←
25 CAPACITOR - COMPRESSOR 1 DS371206CPNA
(20µF, 370VAC)
DS371306CPNA
(30µF, 370VAC)
←
0
26 HOLDER CAPACITOR 1 CWH30057
← ←
27 CAPACITOR - FAN MOTOR 1 CWA31618
(2.0µF,
450VAC)
← ←
0
28 CABINET SIDE PLATE (L) 1 CWE041031A
← ←
29 CABINET SIDE PLATE (R) 1 CWE041032A
←
CWE041033A
30 CABINET FRONT PLATE 1 CWE06K1034
← ←
31 WIRE NET 1 CWD041021A
←
CWD041023A
32 CABINET TOP PLATE 1 CWE031014A
← ←
33 PLATE - C. B. COVER 1 CWH131088
← ←
34 CONTROL BOARD COVER 1 CWH131092
← ←
35 HANDLE 1 CWE161010
← ←
36 OPERATION INSTRUCTIONS 1 (1)
(2)
(3)
(4)
CWF563298
CWF563353
-
CWF563389
←
←
CWF563303
←
←
←
←
←
37 INSTALLATION INSTRUCTIONS (ENGLISH,
FRANCAIS, ESPANOL & DEUTSCH)
1 (1)
(2)
(3)
(4)
CWF612188
CWF612188
-
CWF612188
←
←
CWF612188
←
←
←
←
←
38 INSTALLATION INSTRUCTIONS (ITALIANO,
NEDERLANDS, PORTUGUES & GREEK)
1 (1)
(2)
(3)
(4)
CWF612189
-
-
-
←
-
-
-
←
-
-
-
39 INSTALLATION INSTRUCTIONS (RUSSIA) 1 (1)
(2)
(3)
(4)
CWF612202
-
-
-
←
-
-
-
←
-
-
-
40 L-TUBE 1 CWH5850080
← ←
41 TUBE ASS’Y (CHECK VALVE/CAPILLARY) 1 CWT01C2314 CWT01C2311 CWT01C2308
42 ELECTRO MAGNETIC SWITCH 1 CWA00059
← ←
0
43 ELECTROLYTIC CAPACITOR 1 CWA32C067
← ←
0
44 ELECTRO MAGNETIC SWITCH 1 K6C2C7A00001
← ←
0
45 TEMPERATURE RELAY 1 CWA14C1001
← ←
0
46 V-COIL COMPLETE 1 CWA43C2069
←
CWA43C2054 0
(Note)
• All parts are supplied from MACC, Malaysia (Vendor Code: 086).
• “O” marked parts are recommended to be kept in stock.
• (1) — CU-A7BKP5, CU-A9BKP5, CU-A12BKP5 (Europe).
• (2) — CU-A7BKP5-2, CU-A9BKP5-2, CU-A12BKP5-2 (Oceania).
• (3) — CU-A9BKP5-3, CU-A12BKP5-3 (Argentina).
• (4) — CU-A7BKP5-6, CU-A9BKP5-6, CU-A12BKP5-6 (Turkey).
77
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6
