16 Replacement Parts List
<Model: CU-A12CTP5>
REF. NO. PART NAME & DESCRIPTION QTY. CU-A12CTP5 REMARKS
1 CHASSY ASS’Y 1 CWD50K2074
2 SOUND PROOF MATERIAL 1 CWG302110
3 FAN MOTOR BRACKET 1 CWD541030
4 SCREW - FAN MOTOR BRACKET 2 CWH55413
5 FAN MOTOR 1 CWA951121 0
6 SCREW - FAN MOTOR MOUNT 3 CWH55406
7 PROPELLER FAN ASS’Y 1 CWH03K1006
8 NUT - PROPELLER FAN 1 CWH56053
9 COMPRESSOR 1 QJ208PAA 0
10 ANTI - VIBRATION BUSHING 3 CWH501024
11 NUT - COMPRESSOR MOUNT 3 CWH4582065
12 CONDENSER 1 CWB32C1266
13 4-WAY VALVE 1 CWB00003 0
14 STRAINER 1 CWB11025
15 HOLDER COUPLING ASS’Y 1 CWH351023
16 2-WAY VALVE (LIQUID) 1 CWB021119 0
17 3-WAY VALVE (GAS) 1 CWB011105 0
18 OVERLOAD PROTECTOR 1 CWA121060 0
19 HOLDER - O.L.P. 1 -
20 TERMINAL COVER 1 CWH171021
21 NUT - TERMINAL COVER 1 CWH561020
22 SOUND PROOF BOARD 1 CWH151023
23 CONTROL BOARD 1 CWH102102
24 TERMINAL BOARD ASS’Y 1 CWA28K1034
25 CAPACITOR - COMPRESSOR 1 DS371306CPNA
(30µF, 370VAC)
0
26 HOLDER CAPACITOR 1 CWH30057
27 CAPACITOR - FAN MOTOR 1 CWA31618
(2.0µF, 450VAC)
0
28 CABINET SIDE PLATE (L) 1 CWE041031A
29 CABINET SIDE PLATE (R) 1 CWE041033A
30 CABINET FRONT PLATE 1 CWE06K1034
31 WIRE NET 1 CWD041023A
32 CABINET TOP PLATE 1 CWE031014A
33 PLATE - C. B. COVER 1 CWH131088
34 CONTROL BOARD COVER 1 CWH131092
35 HANDLE 1 CWE161010
36 OPERATION INSTRUCTIONS 1 CWF563868
37 INSTALLATION INSTRUCTIONS (ENGLISH, FRANCAIS, ESPANOL &
DEUTSCH)
1 CWF612347
38 INSTALLATION INSTRUCTIONS (ITALIANO, NEDERLANDS, PORTUGUES &
GREEK)
1 CWF612348
39 INSTALLATION INSTRUCTIONS (RUSSIA) 1 CWF612349
40 L-TUBE 1 CWH5850080
41 TUBE ASS’Y (CHECK VALVE/CAPILLARY) 1 CWT01C2730
42 ELECTRO MAGNETIC SWITCH 1 CWA00059 0
43 ELECTROLYTIC CAPACITOR 1 CWA32C067 0
44 ELECTRO MAGNETIC SWITCH 1 K6C2C7A00001 0
45 TEMPERATURE RELAY 1 CWA14C1009 0
46 V-COIL COMPLETE 1 CWA43C2054 0
47 TUBE ASS’Y (RECEIVER) 1 CWT01C2731
(Note)
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
58
CS-A12CTP CU-A12CTP5 / CS-A18CTP CU-A18CTP5 / CS-A24CTP CU-A24CTP5
