Panasonic CS-A12CTP

18 Replacement Parts List
<Model: CU-A18CTP5 / CU-A24CTP5>
REF. NO. PART NAME & DESCRIPTION QTY. CU-A18CTP5 CU-A24CTP5 REMARKS
1 CHASSY ASS’Y 1 CWD50K514B
←
2 SOUND PROOF BOARD 1 CWH15223
←
3 FAN MOTOR BRACKET 1 CWD54237
←
4 SCREW - FAN MOTOR BRACKET 4 CWH55027
←
5 FAN MOTOR 1 CWA921182 CWA921081 0
6 SCREW - FAN MOTOR MOUNT 4 CWH55252
←
7 PROPELLER FAN ASS’Y 1 CWH00K087 CWH00K1001
8 NUT - PROPELLER FAN 1 CWH56053 CWH56060
9 COMPRESSOR 1 2JS350D3EA02 2JS464D3CA02 0
10 PACKING 1 CWB81043
←
11 ANTI - VIBRATION BUSHING 3 CWH50055
←
12 NUT - COMPRESSOR MOUNT 3 CWH4582065
←
13 SOUND PROOF MATERIAL 1 CWG30894
←
14 CONDENSER 1 CWB32C345R
←
15 HOLDER COUPLING ASS’Y 1 CWH35K029B CWH35K030B
16 3-WAY VALVE (LIQUID) 1 CWB01495
←
0
17 3-WAY VALVE (GAS) 1 CWB01364 CWB01430 0
18 4-WAY VALVE ASS’Y 1 CWB00K1007 CWB00K1008 0
19 TUBE ASS’Y (CAPILLARY TUBE & STRAINER) 1 CWT01C2682 CWT01C2672
20 V-COIL COMPLETE 1 CWA43C2005
←
0
21 TERMINAL COVER 1 CWH171012
←
22 NUT - TERMINAL COVER 1 CWH7080300
←
23 CONTROL BOARD 1 CWH10K1019
←
24 CAPACITOR - FAN MOTOR 1 F0GAH305A002
←
0
25 CAPACITOR - COMPRESSOR 1 DS371506CPNA
←
0
26 HOLDER CAPACITOR 1 CWH30060
←
27 TERMINAL BOARD ASS’Y 1 CWA28K1021
←
28 ELECTRONIC CONTROLLER 1 CWA743072
←
30 SENSOR COMPLETE 1 CWA50C618
←
31 HOLDER - SENSOR 1 CWH32089
←
32 CABINET FRONT PLATE 1 CWE06K034B
←
33 CABINET REAR PLATE 1 CWE02096B
←
34 CABINET FRONT PLATE 1 CWE06075B
←
35 CABINET SIDE PLATE 1 CWE04111B
←
36 CABINET TOP PLATE 1 CWE03101B
←
37 CONTROL BOARD COVER 1 CWH13336A
←
38 HANDLE 2 CWE16000E
←
39 OPERATION INSTRUCTIONS 1 CWF563868
←
40 INSTALLATION INSTRUCTIONS (ENGLISH, FRANCAIS,
ESPANOL & DEUTSCH)
1 CWF612347
←
41 INSTALLATION INSTRUCTIONS (ITALIANO, NEDERLANDS,
PORTUGUES & GREEK)
1 CWF612348
←
42 INSTALLATION INSTRUCTIONS (RUSSIA) 1 CWF612349
←
43 PARTICULATE PLATE 1 CWD90830
←
44 TUBE ASS’Y (RECEIVER) 1 CWT01C2448
←
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
60
CS-A12CTP CU-A12CTP5 / CS-A18CTP CU-A18CTP5 / CS-A24CTP CU-A24CTP5
