Unit CS-A12CTP CU-A12CTP5
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium (Blue Coated)
Fin Type Louver Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2×12 2×24
FPI 20 16
Size (W × H × L) mm 857 × 252 × 25.4 720 × 504 × 36.38
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GSI (410)
Refrigerant (R-22) g (oz.) — 920 (32.5)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling: 630, Heating: 455
Flow Rate l/min — Cooling: 6.5, Heating: 13.6
Inner Diameter mm — Cooling: 1.2, Heating: 1.5
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 440VAC 2.0 µF, 450VAC
•
Specifications are subject to change without notice for further improvement.
6
CS-A12CTP CU-A12CTP5 / CS-A18CTP CU-A18CTP5 / CS-A24CTP CU-A24CTP5
