10
ENGLISH
HEAT – Heating Operation
■ Defrosting Operation
Depend on the outdoor temperature, the operation
occasionally stops to melt the frost on the outdoor
unit.
■ Heat is obtained from outdoor air to warm up the
room. When the outdoor ambient air temperature
falls, the heating capacity of the unit might be
reduced.
Automatic Airflow Volume
■ The speed of the indoor fan is adjusted automati-
cally according to the operation. The indoor fan
stops occasionally during cooling operation.
Range of louver adjustment
34°
57°
46°
Heating
(Airflow
Direction Manual)
Heating
(Airflow
Direction Auto)
Cooling/Soft Dry
(Airflow Direction
Manual and Auto)
SWING
MANUAL
1
2
3
4
5
m n
2°C lower than
standard
standard
n
n o
2°C higher than
standard
▼
MANUAL
▼
OFF/ON I
FAN SPEED
MODE
i
TEMP.
MANUAL
SWING
Press to select operation mode.
■ The display changes in the order
each time the button is pressed.
Press to start the operation.
■ Operation indication lamp (RED) will light up.
■ Press once more, to stop the operation.
Press to select airflow volume.
■ The display changes in the order.
Automatic Low Medium High
Press to select room temperature.
■ Heating, Cooling, Soft Dry – Select temperature as desired.
(16°C ~ 30°C)
■ Automatic. (See <Operation Details>)
Press continuously.
■ The vertical airflow direction louver will move up and down. Release the
button when the louver is at the desired position.
Press .
■ Cooling & Soft Dry – The vertical airflow direction louver will swing up and down
automatically.
Heating – When the discharge air temperature is low such as at the start of
heating operation, the air blows at horizontal level. As the
temperature rises, the hot air blows in a downwards direction.
To stop the automatic airflow direction operation, press button.
To Next Page
