15.2. COOLING PERFORMANCE
Model Cooling capacities are based on conditions below.
CS-A18BB4P
Cooling capacity
5.0 kW
1 phase, 50Hz, 220V
Indoor temperature 27°C D.B. 19°CW.B.
Outdoor temperature 35°C D.B.
Standard air volume 14m
3
/min
Entering Temperature Air Entering Condenser (°C D.B.)
Air 25 30 35 40 43
Temperature TC TC TC TC TC
D.B. W.B. kW kW kW kW kW
17 5.00 4.75 4.50 4.20 4.00
23 19 5.28 5.04 4.77 4.49 4.28
22 5.65 5.34 5.10 4.81 4.58
17 5.04 4.80 4.56 4.24 4.03
25 19 5.40 5.14 4.89 4.57 4.34
22 5.82 5.50 5.23 4.94 4.69
17 5.08 4.84 4.61 4.29 4.06
27 19 5.51 5.25 5.00 4.65 4.40
22 5.99 5.67 5.35 5.07 4.80
17 5.14 4.89 4.67 4.34 4.11
29 19 5.58 5.31 5.06 4.71 4.45
22 6.03 5.72 5.40 5.12 4.84
17 5.19 4.93 4.70 4.38 4.14
32 19 5.63 5.35 5.10 4.75 4.49
22 6.05 5.75 5.43 5.15 4.87
35
