Panasonic CS-A18BB4P - Position of the Center Gravity

17 POSITION OF THE CENTER GRAVITY
MODEL NAME OUTSIDE DIMENSIONS NET WEIGHT CENTRE OF GRAVITY
WIDTH (mm) DEPTH (mm) HEIGHT (mm) kg X (mm) Y (mm) Z (mm)
CU-A18BBP5 800 300 685 56 560 160 360
CU-C18BBP5 800 300 685 52 560 160 360
38
