Panasonic CS-A18DKD

18 Replacement Parts List (Outdoor Unit)
18.1. CU-A18DKD CU-A24DKD
REF. NO. PART NAME & DESCRIPTION QTY. CU-A18DKD CU-A24DKD REMARKS
1 CHASSY ASS’Y 1 CWD50K2087
←
2 COMPRESSOR 1 2JS324D3AB07 2JS438D3JA02 0
3 ANTI - VIBRATION BUSHING 3 CWH50055
←
4 NUT - COMPRESSOR MOUNT 3 CWH4582065
←
5 PACKING 3 CWB81043
←
6 CONDENSER 1 CWB32C1349 CWB32C1350
7 SOUND PROOF BOARD ASS’Y 1 CWH151051
←
8 FAN MOTOR BRACKET 1 CWD541055
←
9 SCREW - FAN MOTOR BRACKET 2 CWH551060
←
10 FAN MOTOR 1 CWA951385
←
0
11 SCREW - FAN MOTOR MOUNT 3 CWH55252
←
12 PROPELLER FAN ASS’Y 1 CWH03K1017
←
13 NUT - PROPELLER FAN 1 CWH561038
←
14 HOLDER COUPLING 1 CWH351036
←
15 2-WAY VALVE (LIQUID) 1 CWB021173
←
0
16 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT01C3391 CWT01C3390
17 3-WAY VALVE (GAS) 1 CWB011212 CWB011213 0
18 TERMINAL COVER 1 CWH171012
←
19 NUT - TERMINAL COVER 1 CWH7080300
←
20 CONTROL BOARD CASING 1 CWH102206
←
21 CAPACITOR-F.M 1 DS441355NPQA
←
0
22 CAPACITOR - COMP 1 CWA312079
←
0
23 HOLDER CAPACITOR 1 CWH30060
←
24 TERMINAL BOARD ASS’Y 1 CWA28K1070
←
25 CABINET SIDE PLATE (L) 1 CWE041082A
←
26 HANDLE 1 CWE161010
←
27 CABINET SIDE PLATE (R) 1 CWE041083A
←
28 HANDLE 2 CWE16000E
←
29 CABINET FRONT PLATE ASS’Y 1 CWE06K1043
←
30 WIRE NET COMPLETE 1 CWD041041A
←
31 CABINET TOP PLATE ASS’Y 1 CWE03K1009A
←
32 CONTROL BOARD COVER 1 CWH131168
←
33 CONTROL BOARD COVER COMPLETE 1 CWH131169A
←
34 OPERATION INSTRUCTIONS 1 CWF564548
←
35 INSTALLATION INSTRUCTIONS 1 CWF612685
←
36 SENSOR COMPLETE 1 CWA50C618
←
0
38 SOUND PROOF MATERIAL 1 CWG30221
←
39 ELECTRONIC CONTROLLER 1 CWA743367
←
0
40 4-WAY VALVE ASS’Y 1 CWB00K1025 CWB00K1026 0
41 V-COIL COMPLETE 1 CWA43C2121
←
0
43 HOLDER SENSOR 1 CWH32089
←
44 HOLDER SENSOR 1 CWH32074
←
45 INSTALLATION INSTRUCTIONS 1 CWF612686
←
46 INSTALLATION INSTRUCTIONS 1 CWF612718
←
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
76
CS-A18DKD CU-A18DKD / CS-A24DKD CU-A24DKD
