Panasonic CS-A18EKH - Page 62

62
(NOTE)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
REF. NO. PART NAME & DESCRIPTION QTY. CS-A18EKH CS-A24EKH REMARKS
1 CHASSY COMPLETE 1 CWD50C1394 ←
2 FAN MOTOR 1 CWA981149J ← 0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1010 ←
4 SCREW - CROSS FLOW FAN 1 CWH551146 ←
5 BEARING ASS’Y 1 CWH64K007 ←
6 EVAPORATOR 1 CWB30C1549 CWB30C1572
7 FLARE NUT (1/4”) 1 CWT251026 ←
8 FLARE NUT (1/2”) (5/8”) 1 CWT251035 CWT251036
9 INTAKE AIR SENSOR HOLDER 1 CWH32143 ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2500 ←
11 VERTICAL VANE 16 CWE241088 ←
12 CONNECTING BAR 1 CWE261025 ←
13 AIR SWING MOTOR 1 CWA981106J ← 0
13a LEAD WIRE - AIR SWING MOTOR 1 CWA67C3849 ←
14 AIR SWING MOTOR 1 CWA98K1008 ← 0
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3731 ←
16 HORIZONTOL VANE 1 CWE241152 ←
17 HORIZONTOL VANE 1 CWE241153 ←
18 CAP - DRAIN TRAY 1 CWH52C1001 ←
19 BACK COVER CHASIS 1 CWD932162B ←
20 CONTROL BOARD CASING 1 CWH102291 ←
21 TERMINAL BOARD COMPLETE 1 CWA28C2140 CWA28C2141 0
22 POWER SUPPLY CORD 1 CWA20C2506 CWA20C2510
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C2041 CWA73C2048 0
23a ELECTRONIC CONTROLLER - POWER 1 CWA744052 ← 0
24 INDICATOR COMPLETE 1 CWE39C1152 ← 0
25 INDICATOR HOLDER 1 CWD932435 ←
26 INDICATOR HOLDER 1 CWD932436 ←
27 SENSOR COMPLETE 1 CWA50C2122 ← 0
28 CONTROL BOARD TOP COVER 1 CWH131209 ←
29 CONTROL BOARD FRONT COVER 1 CWH131210 ←
30 REMOTE CONTROL COMPLETE 1 CWA75C2823 ← 0
31 FRONT GRILLE COMPLETE 1 CWE11C3458 CWE11C3559 0
32 INTAKE GRILLE COMPLETE 1 CWE22C1159 ←
33 GRILLE DOOR 1 CWE141076 ←
34 AIR FILTER (L) 1 CWD001137 ←
35 AIR FILTER (R) 1 CWD001138 ←
36 SCREW - FRONT GRILLE 3 XTT4+16CFJ ←
37 CAP - FRONT GRILLE 3 CWH521062A ←
38 DRAIN HOSE 1 CWH851063 ←
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 ←
40 INSTALLATION PLATE 1 CWH36K1007 ←
41 FULCRUM 2 CWH621047 ←
42 SUPERSONIC AIR PURIFYING DEVICE 1 CWH91C1016 ←
43 ELEC. CONTROLLER - SUPERSONIC 1 CWA744249 ← 0
44 SUPER ALLERU BUSTER FILTER 1 CWD00C1161 ← 0
45 FRAME FR AIR FILTER SUPERSONIC 1 CWD011035 ←
46 FRAME FR AIR FILTER SUPERSONIC 1 CWD011027 ←
47 AIR FILTER - SUPERSONIC 1 CWD001147 ←
48 DEODORIZING FILTER 1 CWD001192 ←
