8
Note
• Specifications are subject to change without notice for further improvement.
Air Circulation Description Cross-flow Fan Propeller Fan
Material ASHT-18 PP
Motor Type Transistor (8-poles) Induction (6-poles)
Input W — 116 - 127
Rated Output W 30 80
Fan Speed Low rpm Cooling; 1,280 - 1,280
Heating; 1,380 - 1,380
460 - 520
Medium rpm Cooling; 1,480 - 1,480
Heating; 1,480 - 1,480
—
High rpm Cooling; 1,570 - 1,570
Heating; 1,650 - 1,650
815 - 845
SuperHigh rpm Cooling; 1,650 - 1,650 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium
Fin Type Slit Fin Corrugated Fin
Row/Stage (Plate fin configuration, forced draft)
2 × 15 2 × 28
FPI 21 18
Size (W × H × L) mm 810 × 315 × 25.4 827.7 × 711.2 × 44.0
862.2
Refrigerent Control Device — Capillary Tube
Refrigeration Oil
(cm
3
)
— SUNISO 4GDID or ATMOS
M60 or ATMOS 56M (1,130)
Refrigerant (R-22) g (oz) — 2,050 (72.4)
Thermostat ——
Protection Device — Inner Protector
Capillary Tube Length mm — Cooling; 730, Heating; 340
Flow Rate l/mm — Cooling; 12.5, Heating; 21.0
Inner Diameter mm — Cooling; 1.6, Heating; 2.0
Air Filter Material
Style
P. P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 45 µF, 400/440VAC
Fan Motor Capacitor µF, VAC — 3.5 µF, 440VAC
Unit CS-A24EKH CU-A24EKH
