7
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C D.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
Note
• Specifications are subject to change without notice for further improvement.
ITEM UNIT
Power Source (Phase, Voltage, Cycle) ø Single
V 220 - 230
Hz 50
Input Power kW Cooling: 2.54 - 2.58
Heating: 2.53 - 2.56
Starting Current A 65
Running Current A Cooling: 12.3 - 12.2
Heating: 12.2 - 12.2
Power Factor % Cooling: 94 - 92
Heating: 94 - 91
Power factor means total figure of compressor, indoor fan motor and outdoor fan motor.
*Maximum over current protection A 15.8
Number of Core
3 (2.5mm
2
)
Power Cord Length m 1.9
Thermostat —
Protection Device Inner Protector
