2.2. CS-A24GKD CU-A24GKD
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition NEW JIS
C
O
O
L
I
N
G
Capacity
kW 7.03 - 7.03
BTU/h 24,000 - 24,000
EER
W/W 2.77 - 2.72
BTU/hW 9.45 - 9.30
Noise Level dB (A) High 47 - 47, Low 41 - 41 High 53 - 54
H
E
A
T
I
N
G
Capacity
kW 7.80 - 7.80
BTU/h 26,600 - 26,600
COP
W/W 3.08 - 3.05
BTU/hW 10.51 - 10.39
Noise Level dB (A) High 46 - 46, Low 41 - 41 High 54 - 55
Moisture Removal
I/h 4.0
pt/h 8.5
Lo
m
3
/min (ft
3
/min)
Cooling; 13.7 (480) - 13.7 (480)
Heating; 14.7 (520) - 14.7 (520)
28.1 (990) - 29.9 (1,060)
Air Volume
Me
m
3
/min (ft
3
/min)
Cooling; 15.8 (560) - 15.8 (560)
Heating; 15.8 (560) - 15.8 (560)
—
Hi
m
3
/min (ft
3
/min)
Cooling; 16.8 (590) - 16.8 (590)
Heating; 17.6 (620) - 17.6 (620)
49.7 (1,750) - 50.7 (1,790)
SHi
m
3
/min (ft
3
/min)
Cooling 17.7 (630) - 17.7 (630)
—
Refrigeration Control Device — Capillary Tube
Refrigeration Oil
cm
3
—
SUNISO 4GDID or ATMOS
M60 or ATMOS 56M (1,130)
Refrigerant (R22) g (oz) — 2,050 (72.4)
Dimension
Height mm (inch) 275 (10-13/16) 750 (29-17/32)
Width mm (inch) 998 (39-9/32) 875 (34-7/16)
Depth mm (inch) 230 (9-1/16) 345 (13-19/32)
Net Weight kg (lbs) 11.0 (24) 63.0 (139)
Pipe Diameter
Gas mm (inch) 15.8 (5/8)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 5 (16.4)
Pipe Length Range m (ft) 3 (9.8) ~ 25 (82.0)
Height Difference m (ft) 20.0 (65.6)
Additional Gas Amount g/m (oz/ft) 30 (0.3)
Refrigeration Charges Less m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16 —
Length mm 650 —
Compressor
Type —
Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-pole)
Rated Output kW — 2.0
Fan
Type Cross-Flow Fan Propeller Fan
Material ASHT-18 PP
Motor Type Transistor (8-poles) Induction (6-poles)
Input Power W — 116 - 127
Output Power W 30 80
Fan Speed
Lo
rpm
Cooling; 1,280 - 1,280
Heating; 1,380 - 1,380
460 - 490
Me
rpm
Cooling; 1,480 - 1,480
Heating; 1,480 - 1,480
—
Hi
rpm
Cooling; 1,570 - 1,570
Heating; 1,650 - 1,650
815 - 830
Shi rpm Cooling; 1,650 - 1,650 —
Heat Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Blue Coated)
Fin Type Slit Fin Corrugated Fin
Row x Stage X FPI 2 x 15 x 21 2 x 28 x 18
Size (W x H x L) mm
810 x 315 x 25.4 44 x 711.2 x 791
826
Air Filter
Material Polypropelene —
Type One-Touch —
