• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
[PHAAM] Printed in Malaysia
SPYW0612-01
REF. NO. PART NAME & DESCRIPTION QTY. CU-A18GKD CU-A24GKD REMARKS
1 CHASSY ASS’Y 1 CWD50K2087 ←
2 COMPRESSOR 1 2JS324D3AB07 2JS438D3JA02 0
3 ANTI - VIBRATION BUSHING 3 CWH50055 ←
4 NUT - COMPRESSOR UNIT 3 CWH561049 ←
5 PACKING 3 CWB81043 ←
6 CONDENSER 1 CWB32C2042 CWB32C2044
7 SOUND PROOF BOARD ASS’Y 1 CWH151051 ←
8 FAN MOTOR BRACKET 1 CWD541055 ←
9 SCREW - FAN MOTOR BRACKET 3 CWH551198 ←
10 FAN MOTOR 1 CWA951385J ← 0
11 SCREW - FAN MOTOR MOUNT 3 CWH55252J ←
12 PROPELLER FAN ASS’Y 1 CWH03K1017 ←
13 NUT - PROPELLER FAN 1 CWH561038J ←
14 HOLDER COUPLING 1 CWH351036 ←
15 2-WAY VALVE (LIQUID) 1 CWB021361 ← 0
16 TUBE ASS’Y (CAPILLARY TUBE & CHECK VALVE) 1 CWT01C3391 CWT01C3390
17 3-WAY VALVE (GAS) 1 CWB011212 CWB011213 0
18 TERMINAL COVER 1 CWH171012 ←
19 NUT- TERMINAL COVER 1 CWH7080300J ←
20 CONTROL BOARD CASING 1 CWH102206 ←
21 CAPACITOR - F.M 1 DS441355NPQA ← 0
22 CAPACITOR - COMP 1 CWA312079 ← 0
23 HOLDER CAPACITOR 1 CWH30060 ←
24 TERMINAL BOARD ASS’Y 1 CWA28K1070J ←
25 CABINET SIDE PLATE (L) 1 CWE041255A CWE041082A
26 HANDLE 1 CWE161010 ←
27 CABINET SIDE PLATE (R) 1 CWE041083A ←
28 HANDLE 2 CWE16000E ←
29 CABINET FRONT PLATE ASS’Y 1 CWE06K1043 ←
31 CABINET TOP PLATE ASS’Y 1 CWE03K1009A ←
32 CONTROL BOARD COVER 1 CWH131168 ←
33 CONTROL BOARD COVER COMPLETE 1 CWH131169A ←
34 OPERATION INSTRUCTIONS 1 CWF565500 ←
35 INSTALLATION INSTRUCTIONS 1 CWF613102 ←
38 SOUND PROOF MATERIAL 1 CWG302221 ←
39 ELECTRONIC CONTROLLER 1 CWA743367 ← O
40 4-WAY VALVE ASS’Y 1 CWB001026J ← O
41 V-COIL COMPLETE 1 CWA43C2121J ← O
43 HOLDER SENSOR 1 CWH32089 ←
44 HOLDER SENSOR 1 CWH32074 ←
45 SENSOR COMPLETE 1 CWA50C618 ←
46 DRAIN HOSE 1 CWG87C900 ←
48 OPERATION INSTRUCTIONS 1 CWF565501 ←
49 INSTALLATION INSTRUCTIONS 1 CWF613103 ←
50 WIRE NET 1 CWD041041A ←
