3-way Valve (Liquid Side) 3-way Valve (Gas
Side)
Works Shaft Position Service Port Shaft Position
Service
Shipping Close Closed Closed
Closed
(With valve cap) (With cap) (With valve cap) (
With
Evacuation Closed Open Closed
Open
(Installation and (Clockwise) (Connected manifold (Clockwise) (
Push
Re-installation) gauge w/charging
cylinder)
Operation Open Closed Open
Closed
(With valve cap) (With cap) (With valve cap) (
With
Pumping down Closed Closed Open
Open
(Transferring) (Clockwise) (With cap) (Counter-Clockwise) (
Connected
manifold
Evacuation Open Open Open
Open
(Servicing) (Counter-Clockwise) (Connected manifold (Counter-Clockwise)(
Connected
gauge)
gauge)
Gas charging Open Open Open
Open
(Servicing) (Counter-Clockwise) (Connected manifold (Counter-Clockwise)(
Connected
gauge)
gauge)
46
