Panasonic CS-A281 KR - Electronic Circuit Diagram

SYMBOL DESCRIPTION & NAME PART NO.
IC1 INTEGRATED CIRCUIT A52C78414Y
IC2 INTEGRATED CIRCUIT A52C094
IC3 INTEGRATED CIRCUIT A52C040
IC4 INTEGRATED CIRCUIT A52MPA2003C
Q1 TRANSISTOR
A55C1740STPQ
Q2 TRANSISTOR A55DTC113ZST
D1 ~ D6 DIODE A54MA165TA5
DB1, DB2 DIODE BRIDGE A54CS1VB20E
ZD1 ZENER DIODE A54D7.5EL1TB
ZNR2 ~ ZNR4 ZNR A54C353
T1, T2 TRANSFORMER A40378
CR1 SURGE ABSORBER A59014
CR2 SURGE ABSORBER A59014
RY-HOT RELAY A00160
RY-DEICE RELAY A00160
RY-OFF RELAY A00160
RY-H/L RELAY A00160
RY-V RELAY A00160
FUSE FUSE XBA2C31TR0
X1 RESONATOR
A45ST4.0MGWT
Note
- All parts are supplied from MACC, Malaysia (Vendor Code: 086).
Electronic Controller: C3919-400 (CU-A281KR)
SYMBOL DESCRIPTION & NAME PART NO.
IC1, IC2 INTEGRATED CIRCUIT J4083-070
Q1, Q2 TRANSISTOR C4086-250T
D1 ~ D5, D7 DIODE E4060-020T
RY-C, RY-L RELAY ELECTRO MAGNETIC C4104-090
Q3 TRANSISTOR J4086-080T
Note
- All parts are supplied from TAMACO, Taiwan.
20. Electronic Circuit Diagram
75
