SYMBOL DESCRIPTION & NAME PART NO.
IC1 INTEGRATED CIRCUIT C4083-910
IC2 INTEGRATED CIRCUIT C4083-450
IC3 INTEGRATED CIRCUIT C4083-860
IC4 INTEGRATED CIRCUIT C4083-730
IC5 INTEGRATED CIRCUIT C4083-720
PC1 PHOTO COUPLER C4094-040
Q1 TRANSISTOR C4086-060T
Q2 TRANSISTOR C4086-240T
Q3, Q5 TRANSISTOR J4086-080T
D1 ~ D4 DIODE E4060-020T
ZD1 ZENER DIODE C4082-100T
ZNR1, ZNR2, ZNR3 ZNR C4084-150
RY-HOT RELAY ELECTRO MAGNETIC C4104-180
RY-HI, ME, LO RELAY ELECTRO MAGNETIC C4104-170
RY-COMP RELAY ELECTRO MAGNETIC C4076-310
SSR1 SSR C4092-060
SW1, SW2 PUSH SWITCH C4001-200
FUSE FUSE XBA2C31TR0
X1 RESONATOR F4090-010T
BZ BUZZER (SOUND GENERATOR) C4091-030
Q6~ Q8 TRANSISTOR C4086-250T
Note
- All parts are supplied from TAMACO, Taiwan.
Electronic Controller: CWA741315 (CU-A281KR)
