NO
DESCRIPTION & NAME
QTY
CS-280KR
REMARKS
40 CAP (FRONT GRILLE COMPLETE) 4 CWH5060060
41 PARTICULAR PLATE 1 CWH4945610
42 RAIN COVER (HOLDER - EVAPORATOR TUBE ASS’Y 1 CWH4631410
43 BAG COMPLETE (AIR PURIFYING FILTER) 1 CWE4649570C
44 REMOTE CONTROL COMPLETE ASS’Y 1 CWA75C556
45 INSTALLATION PLATE 1 CWH8010540
46 OPERATING INSTRUCTIONS 1 CWF8036900
47 INSTALLATION INSTRUCTIONS 1 CWF8039140
48 BAG COMPLETE - INSTALLATION SCREW 1 CWH4649210
49 SCREW 1 XTT4+12C
50 SCREW 1 XTT4+16C
51 SCREW 1 XTN4+8C
52 SCREW 1 XTT4+10C
53 SCREW 1 XTT4+8C
54 REMOTE CONTROL UPPER CASE 1 CWE15C241
55 CONTROL PANEL 1 CWE311064
56 KNOB 1 CWE17196A
57 KNOB 1 CWE17197A
58 CONTACTOR 1 CWA65036C
59 ELECTRONIC CONTROLLER 1 CWA74224
60 INDICATOR 1 CWE39199
61 REMOTE CONTROL LOWER CASE 1 CWE15128A
62 COVER 1 CWB80040A
63 CAP (BUTTON) 1 CWE5060120
64 FUSE COMPLETE 1 CWA4023070C
(Note)
- “ ” marked parts are recommended to be kept in stock.
- “ ” marked parts are supplied from TAMACO, Taiwan.
- “ ” marked parts are supplied from MACC, Malaysia.
17. Exploded View
70
