Unit CS-A7CK CU-A7CK
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 44.8 - 53.5 56 - 64
Rate Output W 15 29
Fan Speed Low rpm Cooling; 780 - 780 —
Heating; 840 - 840
Medium rpm Cooling; 920 - 920
Heating; 920 - 920
—
High rpm (1)
(3)
Cooling; 1,030 - 1,030
Heating; 1,190 - 1,190
805 - 820
(2) Cooling; 1,030 - 1,030
Heating; 1,190 - 1,190
805 - 830
SuperHigh rpm Cooling; 1,190 - 1,190 —
Heating; 1,190 - 1,190
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugate Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 1×20
FPI 19 16
Size (W × H × L) mm 610 × 315 × 25.4 841 × 508 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — SUNISO 4GDID or ATMOS M60
(290)
Refrigerant (R-22) g (oz) — 810 (28.6)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 600, Heating; 650
Flow Rate l/min — Cooling; 5.0, Heating; 11.4
Inner Diameter mm — Cooling; 1.1, Heating; 1.5
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 20 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
Note:
•
Specifications are subject to change without notice for further improvement.
•
(1) — CS-A7CKP/CU-A7CKP5 (Europe & CIS).
•
(2) — CS-A7CKP-2/CU-A7CKP5-2 (Oceania).
•
(3) — CS-A7CKP-6/CU-A7CKP5-6 (Turkey & Tunisia).
7
CS-A7CKP CU-A7CKP5 / CS-A9CKP CU-A9CKP5 / CS-A12CKP CU-A12CKP5
