(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
REF. NO. PART NAME & DESCRIPTION QTY. CU-A7GKD CU-A9GKD
1 CHASSY ASS’Y 1 CWD50K2112 ←
2 SOUND PROOF MATERIAL 1 CWG302255 ←
3 FAN MOTOR BRACKET 1 CWD541075 ←
4 SCREW - FAN MOTOR BRACKET 2 CWH551198 ←
5 FAN MOTOR (AC 30W SINGLE) 1 CWA951387J ←
6 SCREW - FAN MOTOR MOUNT 3 CWH55406J ←
7 PROPELLER FAN ASS’Y 1 CWH03K1020 ←
8 NUT - PROPELLER FAN 1 CWH56053J ←
9 COMPRESSOR 1 2RS122D5BC02 2PS156D3BB02
10 ANTI - VIBRATION BUSHING 3 CWH50077 ←
11 NUT - COMPRESSOR MOUNT 3 CWH56000J ←
12 CONDENSER 1 CWB32C1979 CWB32C1493
13 4-WAY VALVE 1 CWB001024J ←
14 STRAINER 1 CWB11025 ←
15 HOLDER COUPLING 1 CWH351047 ←
16 2-WAY VALVE (LIQUID) 1 CWB021218 CWB021217
17 3-WAY VALVE (GAS) 1 CWB011258 CWB011257
18 OVERLOAD PROTECTOR 1 CWA121050J CWA121210J
19 HOLDER - O.L.P. 1 CWH7041200 ←
20 TERMINAL COVER 1 CWH171011 ←
21 NUT - TERMINAL COVER 1 CWH7080300J ←
22 SOUND PROOF BOARD 1 CWH151074 ←
24 TERMINAL BOARD ASS’Y 1 CWA28K1021J ←
25 CAPACITOR - COM. 1 DS371206CPNA DS371306CPND
26 HOLDER CAPACITOR 1 CWH301038 CWH301035
27 CAPACITOR - F.M 1 DS441205NPQA ←
28 CABINET SIDE PLATE (L) 1 CWE041110A ←
29 CABINET SIDE PLATE COMP. 1 CWE04C1042 ←
30 CABINET FRONT PLATE ASS’Y 1 CWE06K1048 ←
31 WIRE NET 1 CWD041057A ←
32 CABINET TOP PLATE 1 CWE031041A ←
34 CONTROL BOARD COVER 1 CWH13C1099 ←
35 BAG COMPLETE 1 CWG87C900 ←
36 TUBE ASS’Y (CHK VALVE, CAPILLARY) 1 CWT01C3976 —
37 CAPILLARY TUBE ASS’Y 1 — CWB15K1166
38 ELECTRO MAGNETIC SWITCH 1 CWA00059 ←
39 ELCTROLYTIC CAPACITOR 1 CWA32C1003 ←
41 TEMPERATURE RELAY 1 CWA14C1009 ←
42 V-COIL COMPLETE 1 CWA43C2187 ←
45 OPERATION INSTRUCTIONS 1 CWF565377 ←
46 INSTALLATION INSTRUCTIONS 1 CWF613059 ←
47 OPERATION INSTRUCTIONS 1 CWF565456 ←
48 INSTALLATION INSTRUCTIONS 1 CWF613060 ←
49 INSTALLATION INSTRUCTIONS 1 CWF613061 ←
