Panasonic CS-A9CKP Service Manual

Unit CS-A12CK CU-A12CK
Fan
Speed
Low rpm Cooling; 900 -900
Heating; 960 - 960
—
Medium rpm Cooling; 1,120 - 1,120
Heating; 1,120 - 1,120
—
High rpm (1)
(3)
Cooling; 1,260 - 1,260
Heating; 1,300 - 1,300
835 - 845
(2) Cooling; 1,260 - 1,260
Heating; 1,300 - 1,300
835 - 860
SuperHigh rpm Cooling; 1,300 - 1,300
Heating; 1,300 - 1,300
—
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugate Fin
Row / Stage (Plate fin configuration, forced draft)
2 × 15 2 × 24
FPI 21 16
Size (W × H × L) mm 610 × 315 × 25.4 720 × 504 × 18.9
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — SUNISO 4GSI (410)
Refrigerant (R-22) g (oz) — 1,090 (38.5)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 630, Heating; 455
Flow Rate l/min — Cooling; 6.5, Heating; 13.6
Inner Diameter mm — Cooling; 1.2, Heating; 1.5
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
Note:
•
Specifications are subject to change without notice for further improvement.
•
(1) — CS-A12CKP/CU-A12CKP5 (Europe & CIS).
•
(2) — CS-A12CKP-2/CU-A12CKP5-2 (Oceania).
•
(3) — CS-A12CKP-6/CU-A12CKP5-6 (Turkey & Tunisia).
11
CS-A7CKP CU-A7CKP5 / CS-A9CKP CU-A9CKP5 / CS-A12CKP CU-A12CKP5
