20 Replacement Parts List
<Model: CU-2C18BKP5G>
NO. DESCRIPTION & NAME Q’TY CU-2C18BKP5G REMARKS
1 CHASSY ASS’Y 1 CWD50K663A
2 AIR GUIDER FOR PROPELLER FAN 1 CWD31094A
3 SOUND PROOF BOARD 1 CWH15071
4 FAN MOTOR BRACKET 1 CWD54179
5 CONDENSER 1 CWB32C1028
6 FAN MOTOR 1 CWA951179 0
7 PROPELLER FAN 1 CWH00023
8 COMPRESSOR 2 2PS134D2AA01 0
9 3-WAY VALVE (LIQUID SIDE) 2 CWB01383 0
10 3-WAY VALVE (GAS SIDE) 2 CWB01384 0
11 HOLDER COUPLING 1 CWH35083A
12 CAPILLARY TUBE 2 CWB15302
13 CONTROL BOARD 1 CWH102151
14 CAPACITOR - COMPRESSOR 2 CWA312075
(370VAC, 25µF)
0
15 CAPACITOR - FAN MOTOR 1 F0GAH305A002
(450VAC, 3µF)
0
18 TERMINAL BOARD 1 CWA281006 0
19 OVERLOAD PROTECTOR 2 CWA12336 0
20 HOLDER - OVERLOAD PROTECTOR 2 CWH7041200
21 TERMINAL COVER - COMPRESSOR 2 CWH7070204
22 CABINET TOP PLATE 1 CWE03C026
23 CONTROL BOARD COVER 1 CWH13244
24 CABINET FRONT PLATE 1 CWE06C110A
25 CABINET SIDE PLATE 1 CWE04069A
26 FAN GUARD 1 CWD04183
27 HANDLE 1 CWE16000E
28 SOUND - PROOF MATERIAL 2 CWG30267
29 ANTI - VIBRATION BUSHING 6 CWH50049
30 STRAINER 2 CWB11002
31 OPERATING INSTRUCTION 1 CWF563436
32 INSTALLATION INSTRUCTION 1 CWF612239
33 NUT - COMPRESSOR 6 CWH56000
34 HOLDER CAPACITOR 2 CWH30078
35 NUT TERMINAL COVER 2 CWH7080300
36 MAGNETIC RELAY 2 CWA4000088
37 TERMINAL BOARD ASS’Y 1 CWA28K234
38 TERMINAL BOARD 1 CWA4711012
39 ELECTRONIC CONTROLLER 1 CWA742811
40 HOLDER CAPACITOR - FAN 1 CWH301005
41 FUSE 1 XBA2C31TR0
42 INSTALLATION INSTRUCTION 1 CWF612242
43 INSTALLATION INSTRUCTION 1 CWF612243
(Note)
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086).
•
“O” marked parts are recommended to be kept in stock.
