16
8.2. CS-C24HK CU-C24HK
Resistance of Outdoor Fan Motor Windings
Note: Resistance at 20qC of ambient temperature.
Resistance of Compressor Windings
Note: Resistance at 20qC of ambient temperature.
MODEL CU-C24HK
CONNECTION CWA951354J
BLUE-YELLOW 58.0 :
YELLOW-RED 62.1 :
YELLOW-ORANGE 144.6 :
MODEL CU-C24HK
CONNECTION 2JS386D3BA04
C - R 1.290 :
C - S 2.061 :
