2.2. CS-C24HKF CU-C24HKF
1. Cooling capacities are based on indoor temperature of 27qC D.B. (80.6qF D.B.), 19.0qC W.B. (66.2qF W.B.) and outdoor air
temperature of 35qC D.B. (95qF D.B.), 24qC W.B. (75.2qF W.B.)
Item Unit Indoor unit Outdoor unit
Performance Test Condition NEW JIS
Capacity kW 7.03 - 7.03
BTU/h 24000 - 24000
*kJ/h 25310 - 25310
EER W/W 2.99 - 2.85
BTU/hW 10.21 - 9.72
Noise Level dB (A) High: 47 / 48 Low: 40 High: 57 / 58
Power level dB
Moisture Removal l/h 4.0
(pt/h) 8.5
Air Volume Lo
m
3
/m (ft
3
/m)
13.3 (470) - 13.3 (470)
Me
m
3
/m (ft
3
/m)
15.3 (541) - 15.3 (541)
Hi
m
3
/m (ft
3
/m)
16.6 (590) - 16.6 (590) 52.0 (1840) - 54.0 (1910)
SHi
m
3
/m (ft
3
/m)
17.8 (627) - 17.8 (627)
Refrigerant Control Device Capillary Tube
Refrigerant Oil (Charged)
cm
3
ATMOS M60 or
SUNISO 4GDID (700cm
3
)
Refrigerant (Charged) R22 kg (oz) 1.61 (56.8)
Dimension Height mm (inch) 275 (10 - 27/32) 750 (29 - 17/32)
Width mm (inch) 998 (39 - 5/16) 875 (34 - 15/32)
Depth mm (inch) 230 (9 - 1/16) 345 (13 - 19/32)
Net Weight kg (lbs) 11 (24) 57 (126)
Pipe Diameter Gas mm (inch) 15.88 (5/8”)
Liquid mm (inch) 6.35 (1/4”)
Height Difference m (ft) 20 (65.6)
Pipe Length Range m (ft) 3 (9.8) - 25 (82.0)
Additional Gas Amount g/m (oz/ft) 30 (0.3)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose Inner diameter mm 16
Length mm 650
Compressor Type Hermetic motor
Motor Type Induction (2-poles)
Rated Output W 1.8k
Fan Type Cross-flow Fan Propeller Fan
Material ASHT-18 PP Resin
Motor Type Transistor (8-poles) Induction (6-poles)
Input power W 60 163.1 - 183.0
Output power W 30 80
Fan Speed Lo (Cool) rpm 1260 - 1260 440 - 500
Me (Cool) rpm 1450 - 1450
Hi (Cool) rpm 1570 - 1570 860 - 890
SHi (Cool) rpm 1680 - 1680
Heat Exchanger Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Louver Fin
Row u Stage u FPI 2 u 15 u 21 2 u 34 u 17
Size (W u H u L) mm 810 u 315 u 25.4 25.4 u 714 u 814.8:834.8
Air Filter Type Material Polypropelene
Style One-touch
