17.1.4. Replacement Parts List (Indoor Unit)
Models:
CS-E15DKEW / CS-E15DKRW / CS-E15DKDW
REF. NO. PART NAME & DESCRIPTION QTY. CS-E15DKEW CS-E15DKRW CS-E15DKDW REMARKS
1 CHASSY COMPLETE 1 CWD50C1431
←
←←
← ←
←←
←
2 FAN MOTOR 1 CWA981149
←
←←
← ←
←←
←
3 CROSS FOLW FAN COMPLETE 1 CWH02C1031
←
←←
← ←
←←
←
4 BEARING ASS’Y 1 CWH64K007
←
←←
← ←
←←
←
5 SCREW - CROSS FLOW FAN 1 CWH4580304
←
←←
← ←
←←
←
6 EVAPORATOR 1 CWB30C1726
←
←←
← ←
←←
←
7 FLARE NUT 1 CWT25086 (1/4")
←
←←
← ←
←←
←
8 FLARE NUT 1 CWT25096 (1/2")
←
←←
← ←
←←
←
9 HOLDER SENSOR 1 CWH32143
←
←←
← ←
←←
←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2343
←
←←
← ←
←←
←
11 VERTICAL VANE 9 CWE241150
←
←←
← ←
←←
←
12 CONNECTING BAR 1 CWE261072
←
←←
← ←
←←
←
13 CONNECTING BAR 1 CWE261065
←
←←
← ←
←←
←
14 AIR SWING MOTOR 2 CWA98260
←
←←
← ←
←←
←
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3849
←
←←
← ←
←←
←
16 CAP - DRAIN TRAY 1 CWH521096
←
←←
← ←
←←
←
17 HORIZONTAL VANE 1 CWE241173
←
←←
← ←
←←
←
18 BACK COVER CHASSIS 1 CWD932454
←
←←
← ←
←←
←
19 CONTROL BOARD CASING 1 CWH102259
←
←←
← ←
←←
←
20 TERMINAL BOARD COMPLETE 1 CWA28C2082
←
←←
← ←
←←
←
21 POWER SUPPLY CORD 1 —
←
←←
← ←
←←
←
22 ELECTRONIC CONTROLLER - MAIN 1 CWA73C1669
←
←←
← ←
←←
←
23 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3977
←
←←
← ←
←←
←
24 SENSOR COMPLETE 1 CWA50C2122
←
←←
← ←
←←
←
25 CONTROL BOARD FRONT COVER 1 CWH13C1120
←
←←
← ←
←←
←
26 INDICATOR COMPLETE 1 CWE39C1126
←
←←
← ←
←←
←
27 INDICATOR HOLDER 1 CWD932429
←
←←
← ←
←←
←
28 INDICATOR HOLDER 1 CWD932430
←
←←
← ←
←←
←
29 CONTROL BOARD TOP COVER 1 CWH131207
←
←←
← ←
←←
←
30 REMOTE CONTROL COMPLETE 1 CWA75C2616
←
←←
← ←
←←
←
31 FRONT GRILLE COMPLETE 1 CWE11C3138
←
←←
← ←
←←
←
32 INTAKE GRILLE 1 CWE22C1154
←
←←
← ←
←←
←
33 GRILLE DOOR 1 CWE141073
←
←←
← ←
←←
←
34 AIR FILTER 2 CWD001144
←
←←
← ←
←←
←
35 SCREW - FRONT GRILLE 2 XTT4+16C
←
←←
← ←
←←
←
36 CAP - FRONT GRILLE 2 CWH521109
←
←←
← ←
←←
←
37 DRAIN HOSE 1 CWH851063
←
←←
← ←
←←
←
38 INSTALLATION PLATE 1 CWH361067
←
←←
← ←
←←
←
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
←
←←
← ←
←←
←
40 FULCRUM 1 CWH621046
←
←←
← ←
←←
←
41 ELECTRONIC CONTROLLER - IONIZER 1 CWA743675
←
←←
← ←
←←
←
42 CASING - IONIZER 1 CWD932464
←
←←
← ←
←←
←
43 CASING - IONIZER 1 CWD932431
←
←←
← ←
←←
←
44 ION GENERATOR 1 CWH94C0001
←
←←
← ←
←←
←
45 SUPERSONIC AIR PURIFYING DEVICE 1 CWH91C1013
←
←←
← ←
←←
←
46 ELECTRONIC CONTROLLER SUPERSONIC 1 CWA743874
←
←←
← ←
←←
←
47 SUPER ALLERU BUSTER FILTER 1 CWD00C1133
←
←←
← ←
←←
←
48 FRAME FR AIR FILTER SUPERSONIC 1 CWD011026
←
←←
← ←
←←
←
49 RRAME FR AIR FILTER SUPERSONIC 1 CWD011027
←
←←
← ←
←←
←
(Note)
•
• •
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
• •
•
“
” marked parts are recommended to be kept in stock.
189
CS-ME7DKEG CS-ME10DD3 EG / CS-ME10DTEG CS-E15DB4EW
