17.4.2. Replacement Parts List (Indoor Unit)
Models:
CS-E15DB4EW / CS-E18DB4EW
REF NO. PART NAME & DESCRIPTION QTY. CS-E15DB4EW CS-E18DB4EW REMARKS
1 BASE PAN ASS’Y 1 CWD52K1100
←
←←
←
2 INNER POLYSTYRENE COMPLETE 1 CWG07C1047
←
←←
←
3 CABINET SIDE PLATE ASS’Y 1 CWE041121
←
←←
←
4 CABINET SIDE PLATE ASS’Y 1 CWE041122
←
←←
←
5 LEAD WIRE - FAN MOTOR 1 CWA67C5136
←
←←
←
6 FAN MOTOR 1 EHDS50A40AC
←
←←
←
7 ANTI-VIBRATION BUSHING 3 CWH501065
←
←←
←
8 CORD HOLDER 1 CWD741024
←
←←
←
9 SCREW - FAN MOTOR 3 CWH7080300
←
←←
←
11 TURBO FAN 1 CWH03K1022
←
←←
←
12 NUT FOR TURBO FAN 1 CWH561042
←
←←
←
13 SP WASHER 1 XWA8
←
←←
←
14 WASHER 1 XWG8H22
←
←←
←
15 EVAPORATOR COMPLETE 1 CWB30C1688
←
←←
←
16 FLARE NUT (1/2") 1 CWT251032
←
←←
←
17 HEATPROOF TUBE 1 CWG021024
←
←←
←
18 HEADPROOF TUBE 1 CWG021064
←
←←
←
19 FLARE NUT (1/4") 1 CWT251030
←
←←
←
21 PIPE COVER 1 CWD93C1050
←
←←
←
22 SENSOR - EVAPORATOR 1 CWA50C2274
←
←←
←
23 HOLD SENSOR 1 CWH32143
←
←←
←
24 EVAPORATOR SURPORTER 3 CWD911529A
←
←←
←
25 TUBE ASS’Y (CAPIL. TUBE) 1 CWT07K1188
←
←←
←
26 DRAIN PUMP COMPLETE 1 CWB53C1015
←
←←
←
27 PANEL DRAIN PUMP ASS’Y 1 CWD93K1008
←
←←
←
28 DRAIN PUMP 1 CWB532043
←
←←
←
29 ANTI - VIBRATION BUSHING 3 CWH501080
←
←←
←
30 FLOAT SWITCH - DRAIN PUMP 1 CWA121215
←
←←
←
31 FLEXIBLE PIPE 1 CWH85C1033
←
←←
←
32 DRAIN NOZZLE 1 CWH411011
←
←←
←
33 DRAIN HOSE HEAT INSULATION 1 CWG321050
←
←←
←
35 DRAIN PAN - COMPLETE 1 CWH40C1034
←
←←
←
36 DRAIN PLUG 1 CWB821008
←
←←
←
37 AIR GUIDER BLOWER WHEEL 1 CWD321058
←
←←
←
38 CONTROL BOARD CASING 1 CWH10K1048
←
←←
←
39 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1778 CWA73C1779
40 SPACER 6 CWH541026
←
←←
←
41 TRANSFORMER 1 CWA40C1030
←
←←
←
43 TERMINAL BOARD - (3 PIN) 1 CWA28K1076
←
←←
←
44 LEAD WIRE - AIR TEMP. SENSOR 1 CWA67C5139
←
←←
←
47 CONTROL BOARD COVER 1 CWH13C1100
←
←←
←
48 ACCESSORY COMPLETE 1 CWH82C127
←
←←
←
48A HEATPROOF TUBE 1 CWG021025
←
←←
←
51 WIRELESS REMOTE CONTROL COMPLETE 1 CWA75C2610
←
←←
←
(Note)
•
• •
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
• •
•
“
” marked parts are recommended to be kept in stock.
