Type Cross-Flow Fan
Material ASG20K1
Motor Type Transistor (8-poles)
Input Power W 94.8
Output Power W 40
Cool rpm 600
QLo
Heat rpm 640
Cool rpm 800
Lo
Heat rpm 980
Cool rpm 1030
Me
Heat rpm 1140
Cool rpm 1260
Hi
Heat rpm 1300
Cool rpm 1290
Indoor Fan
Speed
SHi
Heat rpm 1310
Type Propeller Fan
Material PP
Motor Type DC Motor (6-poles)
Input Power W -
Output Power W 30
Outdoor Fan
Speed Hi rpm 830
Moisture Removal L/h (Pt/h) 2.0 (4.2)
Cool m
3
/min (ft
3
/min) 5.10 (180)
QLo
Heat m
3
/min (ft
3
/min) 5.40 (191)
Cool m
3
/min (ft
3
/min) 7.35 (260)
Lo
Heat m
3
/min (ft
3
/min) 9.20 (325)
Cool m
3
/min (ft
3
/min) 9.90 (350)
Me
Heat m
3
/min (ft
3
/min) 11.00 (388)
Cool m
3
/min (ft
3
/min) 12.5 (440)
Hi
Heat m
3
/min (ft
3
/min) 12.8 (450)
Cool m
3
/min (ft
3
/min) 13.10 (463)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 13.30 (470)
Cool m
3
/min (ft
3
/min) 31.0 (1095)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 31.0 (1095)
Control Device Check Valve & Capillary Tube
Refrigerant Oil cm
3
FV50S (320)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 970 (34.2)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 542 (21-11/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 780 (30-23/32)
Dimension
Depth (I/D / O/D) mm (inch) 214 (8-7/16) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 35 (77)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8)
Standard length m (ft) 5 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6)
