Panasonic CS-E7NKEW User Manual

176
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-E7NKEW CS-E9NKEW CS-E12NKEW CS-E15NKEW REMARK
1 CHASSIS COMPLETE 1 CWD50C1653 ← ← ←
2 FAN MOTOR 1 ARW7628AC ← ← ← o
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1076 ← ← ←
4 BEARING ASSY 1 CWH64K007 ← ← ← o
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ← ← ←
6 GENERATOR COMPLETE 1 CWH94C0043 ← ← ←
7 EVAPORATOR 1 CWB30C2960 CWB30C2755 CWB30C3359 CWB30C3360
8 FLARE NUT (LIQUID) 1 CWT251030 ← ← ←
9 FLARE NUT (GAS) 1 CWT251031 ← ← CWT251032
10 CLIP FOR SENSOR 1 CWH32143 ← ← ←
11 CONTROL BOARD CASING 1 CWH102449 ← ← ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2357 ← ← ← o
13
ELECTRONIC CONTROLLER -
MAIN
1 CWA73C6641 CWA73C6642 CWA73C6643 CWA73C6644 o
14 ELECTRONIC CONTROLLER - HVU 1 N0GE1F000002 ← ← ←
15
ELECTRONIC CONTROLLER -
INDICATOR & RECEIVER
1 CWA746634 ← ← ← o
16 SENSOR COMPLETE 1 CWA50C2401 ← ← ← o
17 SENSOR COMPLETE (ECO) 1 CWA50C2809 ← ← ← o
18
ELECTRONIC CONTROLLER (ECO
SENSOR)
1 CWA745791 ← ← ←
19
ELECTRONIC CONTROLLER (ECO
SENSOR)
1 CWA746206 ← ← ←
20
ELECTRONIC CONTROLLER
(COMPARATOR)
1 CWA746653 ← ← ←
21 LEAD WIRE - PCB ECO 1 CWA67C9785 ← ← ←
22
CONTROL BOARD CASING FOR
PCB ECO
1 CWD933407 ← ← ←
23 CONTROL BOARD TOP COVER 1 CWH131467 ← ← ←
24 INDICATOR HOLDER 1 CWD933406 ← ← ←
25
CONTROL BOARD FRONT COVER
CO.
1 CWH13C1247 ← ← ←
26 DISCHARGE GRILLE COMPLETE 1 CWE20C3235 ← ← ←
27 BACK COVER CHASSIS 1 CWD933233 ← ← ←
28 FULCRUM 1 CWH621131 ← ← ←
29 VERTICAL VANE 8 CWE241374 ← ← ←
30 CONNECTING BAR 1 CWE261250 ← ← ←
31 CONNECTING BAR 1 CWE261256 ← ← ←
32 AIR SWING MOTOR 1 CWA98K1016 ← ← ← o
33 AIR SWING MOTOR 1 CWA981264 ← ← ← o
34 CAP - DRAIN TRAY 1 CWH521096 ← ← ←
35 HORIZONTAL VANE COMPLETE 1 CWE24C1385 ← ← ←
36 REMOTE CONTROL COMPLETE 1 CWA75C3887 ← ← ← o
37 FRONT GRILLE COMPLETE 1 CWE11C5053 ← ← ← o
38 INTAKE GRILLE COMPLETE 1 CWE22C1723 ← ← ←
39 GRILLE DOOR COMPLETE 1 CWE14C1090 ← ← ←
40 AIR FILTER 2 CWD001279 ← ← ← o
41 SCREW - FRONT GRILLE 2 XTT4+16CFJ ← ← ←
42 CAP - FRONT GRILLE 2 CWH521227 ← ← ←
43 DRAIN HOSE 1 CWH851173 ← ← ←
44 INSTALLATION PLATE 1 CWH361097 ← ← ←
45
BAG COMPLETE - INSTALLATION
SCREW
1 CWH82C1705 ← ← ←
46 OPERATING INSTRUCTION 1 CWF56C7825 ← ← ←
50 BAG 1 CWG861497 ← ← ←
51 SHOCK ABSORBER ( L ) 1 CWG713386 ← ← ←

Panasonic CS-E7NKEW Specifications

General

Indoor unit type	Wall-mountable
Indoor units quantity	1
Indoor unit dimensions (WxDxH)	870 x 214 x 290 mm
Timer	Yes
Built-in display	No
Cooling capacity (max)	- BTU/h
Air conditioner functions	cooling, heating
Cooling capacity in watts (max)	2050 W
Heating capacity in watts (max)	2800 W
Cooling energy efficiency (EER, W/W)	4.36
Heating energy efficiency (COP, W/W)	4.41
Outdoor units quantity	0
Noise level (low speed)	20 dB
Noise level (high speed)	37 dB
Noise level (medium speed)	24 dB
Power requirements	AC 230 V
