184
REF. NO. PART NAME & DESCRIPTION QTY. CU-E7NKE CU-E9NKE REMARK
1 CHASSIS COMPLETE 1 CWD50K2073 ←
2 SOUND PROOF MATERIAL 1 CWG302447 CWG302292
3 FAN MOTOR BRACKET 1 CWD541089 ←
4 SCREW - FAN MOTOR BRACKET 2 CWH551217 ←
5 FAN MOTOR 1 CWA951720 CWA951721 o
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J ←
7 PROPELLER FAN ASSY 1 CWH03K1010 ←
8 NUT - PROPELLER FAN 1 CWH56053J ←
9 COMPRESSOR 1 5RS092XCD21 5RS102XBC21 o
10 ANTI - VIBRATION BUSHING 3 CWH50077 ←
11 NUT - COMPRESSOR MOUNT 3 CWH56000J ←
12 CONDENSER 1 CWB32C2985 CWB32C2448
13 TUBE ASSY CO. (CAP./CHK VALVE) 1 CWT01C5305 CWT01C4850
14 DISCHARGE MUFFLER 1 CWB121010 ←
15 HOLDER COUPLING 1 CWH351023 ←
16 2-WAYS VALVE (LIQUID) 1 CWB021559 CWB021457 o
17 3-WAY VALVE (GAS) 1 CWB011374 ← o
19 REACTOR 1 G0C193J00002 ← o
20 TERMINAL COVER 1 CWH171039A ←
21 NUT - TERMINAL COVER 1 CWH7080300J ←
22 SOUND PROOF BOARD 1 CWH151172 ←
23A SOUND PROOF MATERIAL 1 CWG302443 CWG302293
24 SENSOR CO-COMP TEMP 1 CWA50C2205 ← o
25 CONTROL BOARD COVER-TOP 1 CWH131264 ←
26 ELECTRONIC CONTROLLER - MAIN 1 CWA73C6653R CWA73C6655R o
27 TERMINAL BOARD ASSY 1 CWA28K1110J ← o
28 CABINET SIDE PLATE CO. (RIGHT) 1 CWE04C1116 ←
29 SENSOR CO-AIR TEMP AND PIPE TEMP 1 CWA50C2764 ← o
30 CABINET SIDE PLATE (LEFT) 1 CWE041248A ←
31 CABINET FRONT PLATE CO. 1 CWE06C1039 ←
32 CABINET TOP PLATE 1 CWE031014A ←
33 PLATE - C. B. COVER TERMINAL 1 CWH131301 ←
34 CONTROL BOARD COVER CO. 1 CWH13C1211 ←
35 HANDLE 1 CWE161010 ←
38 4-WAYS VALVE 1 CWB001037J ← o
39 V-COIL COMPLETE 1 CWA43C2431 ← o
40 WIRE NET 1 CWD041111A ←
50 BAG-COMPLETE 1 CWG87C900 ←
51 BAG 1 CWG861078 ←
52 BASE BOARD-COMPLETE 1 CWG62C1095 ←
53 SHOCK ABSORBER (RIGHT) 1 CWG712969 ←
54 SHOCK ABSORBER (LEFT) 1 CWG712970 ←
55 C.C. CASE 1 CWG568356 ←
(NOTE)
All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488).
“O” marked parts are recommended to be kept in stock.
To Next Page
