17 Replacement Parts List (Outdoor Unit)
17.1. CU-E9DKE CU-E12DKE
REF NO. DESCRIPTION & NAME QTY. CU-E9DKE CU-E12DKE REMARKS
1 CHASSY ASSY 1 CWD50K2073 ←
2 ANTI-VIBRATION BUSHING 3 CWH50077 ←
3 COMPRESSOR 1 5RS102XBC01 ← O
4 NUT-COMPRESSOR MOUNT 3 CWH56000 ←
5 SOUND PROOF MATERIAL 1 CWG302293 ←
6 FAN MOTOR BRACKET 1 CWD541030 ←
7 FAN MOTOR 1 CWA951418 CWA951309 O
8 SCREW - FAN MOTOR BRACKET 2 CWH551060 ←
9 SCREW - FAN MOTOR MOUNT 4 CWH55406
←
10 PROPELLER FAN ASSY 1 CWH03K1006 ←
11 NUT - PROPELLER FAN 1 CWH56053 ←
12 CONDENSER 1 CWB32C1560 CWB32C1599
13 TUBE ASS’Y CO (CAP./CHK VALVE) 1 CWT01C3257 CWT01C3258
14 HOLDER-COUPLING COMPLETE 1 CWH351023 ←
15 3 WAYS VALVE 1 CWB011296 CWB011297 O
16 4 WAYS VALVE 1 CWB001037 ← O
17 SOUND PROOF MATERIAL 1 CWG302292 ←
18 2 WAYS VALVE 1 CWB021255 ← O
19 DRYER 1 CWB101017 ← O
20 V-COIL COMPLETE 1 CWA43C2143 ← O
21 REACTOR 1 CWA421050 -
22 SENSOR COMPLETE 1 CWA50C2196 ←
23 CONTROL BOARD CASING 1 CWH102273 ←
24 TERMINAL BOARD ASSY 1 CWA28K1110 ←
25 FUSE HOLDERS 1 K5D203BBA002 ←
26 CONTROL BOARD 1 CWH102114 ←
27 CONTROL BOARD 1 CWH102115 ←
28 ELECTRONIC CONTROLLER 1 CWA73C1672R CWA73C1673R O
29 CONTROL BOARD COVER 1 CWH131104 ←
30 SENSOR COMPLETE 1 CWA50C2066 ←
31 HOLDER SENSOR 1 CWH321010 ←
32 TERMINAL COVER 1 CWH171001 ←
33 NUT-TERMINAL COVER 1 CWH7080300 ←
34 CABINET SIDE PLATE CO. 1 CWE04C1011 ←
35 CABINET SIDE PLATE (LEFT) 1 CWE041031A ←
36 HANDLE 1 CWE161010 ←
37 WIRE NET 1 CWD041054A ←
38 CABINET FRONT PLATE CO. 1 CWE06C1039 ←
39 CABINET TOP PLATE 1 CWE031014A ←
40 CONTROL BOARD COVER 1 CWH131110 ←
41 CONTROL BOARD COVER 1 CWH131093
←
42 OPERATING INSTRUCTION (ENG., ESP., ITA., NED.,
POR., GRE., BUL.)
1 CWF564451 ←
43 INSTALLATION INSTRUCTION (ENG., ESP., FRA., DEU.) 1 CWF612674 ←
44 L-TUBE 1 CWH5850080
←
45 INSTALLATION INSTRUCTION (NED., GRE., ITA., POR.) 1 CWF612675 ←
46 INSTALLATION INSTRUCTION (BUL.) 1 CWF612676
←
47 OPERATING INSTRUCTION (FRA., DEU., SWE., NOR.) 1 CWF564445 ←
48 PACKING-L.TUBE 1 CWB81012 ←
49 SOUND PROOF BOARD 1 CWH151025 ←
(Note)
•
All parts are supplied from PHAAM Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
86
CS-E9DKEW CU-E9DKE / CS-E12DKEW CU-E12DKE
