Panasonic CS-E9HKEW Service Manual

11
2.4. CS-E15HKEW CU-E15HKE
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition EUROVENT
C
O
O
L
I
N
G
Capacity
kW 4.40 (0.90 ~ 5.00)
BTU/h 15000 (3070 ~ 17100)
kCal/h 3780 (770 ~ 4300)
EER
W/W 3.21 (4.19 ~ 3.13)
BTU/hW 10.9 (14.3 ~ 10.7)
Noise Level
dB (A) High 43, Low 32, QLo 29 High 46
Power level dB High 54, Low 43, QLo 40 59
H
E
A
T
I
N
G
Capacity
kW 5.50 (0.90 ~ 7.10)
BTU/h 18800 (3070 ~ 24200)
kCal/h 4730 (770 ~ 6110)
COP
W/W 3.50 (3.67 ~ 3.16)
BTU/hW 12.0 (12.5 ~ 10.8)
Noise Level
dB (A) High 43, Low 35, QLo 32 High 46
Power level dB High 54, Low 46, QLo 43 59
Moisture Removal
l/h 2.4
pt/h 5.1
Air Volume
QLo
m
3
/min (ft
3
/min)
Cooling; 5.7 (200)
—
Heating; 8.6 (300)
Lo
m
3
/min (ft
3
/min)
Cooling; 7.0 (250)
—
Heating; 9.3 (330)
Me
m
3
/min (ft
3
/min)
Cooling; 9.4 (330)
—
Heating; 10.8 (380)
Hi
m
3
/min (ft
3
/min)
Cooling; 11.7 (410) Cooling; 48.5 (1710)
Heating; 12.1 (430) Heating; 46.8 (1650)
SHi
m
3
/min (ft
3
/min)
Cooling; 12.18 (430)
—
Heating; 12.2 (430)
Refrigeration Control Device — Expansion Valve
Refrigeration Oil
cm
3
— RB68A or Freol Alpha68M (400)
Refrigerant (R410A) g (oz) — 1.06k (37.4)
Dimension
Height mm (inch) 280 (11-1/32) 750 (29-17/32)
Width mm (inch) 799 (31-15/32) 875 (34-15/32)
Depth mm (inch) 183 (7-7/32) 345 (13-19/32)
Net Weight kg (lbs) 9 (20) 48 (106)
Pipe Diameter
Gas mm (inch) 12.7 (1/2)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 7.5 (24.6)
Pipe Length Range m (ft) 3 (9.8) ~ 15 (49.2)
Height Difference m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 12 —
Length mm 650 —
Compressor
Type — Hermetic Motor
Motor Type — Brushless (4-pole)
Rated Output W — 700
