90
(NOTE)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-E7HKEW CS-E9HKEW CS-E12HKEW CS-E15HKEW REMARKS
1 CHASSY COMPLETE 1 CWD50C1572 mmm
2 FAN MOTOR 1 ARW61G8P30AC mmmO
3 CROSS FLOW FAN COMPLETE 1 CWH02C1045 mmm
4 BEARING ASSY 1 CWH64K007 mmm
5 SCREW - CROSS FLOW FAN 1 CWH551146 mmm
6 EVAPORATOR 1 CWB30C2484 CWB30C2386 CWB30C2388 CWB30C2387
7 FLARE NUT (1/4”) 1 CWT251030 mmm
8 FLARE NUT (3/8”) (1/2”) 1 CWT251031 mmCWT251032
9 CLIP FOR SENSOR 1 CWH32143 mmm
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2621 mmm
11 VERTICAL VANE 12 CWE241157 mmm
12 CONNECTING BAR 1 CWE261092 mmm
13 CONNECTING BAR 2 CWE261071 mmm
14 CONNECTING BAR 1 CWE261091 mmm
15 AIR SWING MOTOR 1 CWA981091 mmmO
17 CAP - DRAIN TRAY 1 CWH521096 mmm
18 HORIZONTAL VANE COMPLETE 1 CWE24C1176 mmm
19 BACK COVER CHASSIS 1 CWD932454 mmm
20 CONTROL BOARD CASING 1 CWH102321 mmm
21 TERMINAL BOARD COMPLETE 1 CWA28C2305 mmmO
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C2957 CWA73C3018 CWA73C3019 CWA73C3020 O
24 ELECTRONIC CONTROLLER - POWER 1 CWA745131 mmmO
25 SENSOR COMPLETE 1 CWA50C2122 mmmO
26 CONTROL BOARD FRONT COVER 1 CWH131207 mmm
27 INDICATOR COMPLETE 1 CWE39C1168 mmmO
28 INDICATOR HOLDER 1 CWD932744 mmm
29 INDICATOR HOLDER 1 CWD932745 mmm
30 CONTROL BOARD FRONT COVER CO. 1 CWH13C1171 mmm
31 REMOTE CONTROL COMPLETE 1 CWA75C3177 mmmO
32 FRONT GRILLE COMPLETE 1 CWE11C3896 mmmO
33 INTAKE GRILLE COMPLETE 1 CWE22C1415 mmm
34 GRILLE DOOR 1 CWE14C1010 mmm
35 E-ION FILTER 2 CWD00K1004 mmm
36 SCREW - FRONT GRILLE 2 XTT4+16CFJ mmm
37 CAP - FRONT GRILLE 2 CWH521109 mmm
38 DRAIN HOSE 1 CWH851063 mmm
39 INSTALLATION PLATE 1 CWH361067 mmm
40 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 mmm
41 FULCRUM 1 CWH621049 mmm
42 E-ION AIR PURIFYING SYSTEM 1 CWH14C5332 mmmO
43 ION - GENERATOR 1 CWH94C0014 mmmO
44 OPERATION INSTRUCTIONS 1 CWF565854 mmCWF565858
45
INSTALLATION INSTRUCTIONS
(ENG., ESP., POR., GRE.)
1 CWF613365
mmCWF613368
46
INSTALLATION INSTRUCTIONS
(NED., FRA., ITA., DEU.)
1 CWF613366 mmCWF613369
