Panasonic CS-E9PB4EA Service Manual

6
Model
Indoor CS-E9PB4EA
Outdoor CU-E9PB4EA
Compressor
Type Hermetic Motor (Rotary)
Motor Type Brushless (4 poles)
Output Power W 900
Indoor Fan
Type SIROCCO FAN
Material ABS
Motor Type DC / Transistor (8-poles)
Input Power W –
Output Power W 40
Speed
QLo
Cool rpm 330
Heat rpm 410
Lo
Cool rpm 370
Heat rpm 440
Me
Cool rpm 460
Heat rpm 510
Hi
Cool rpm 560
Heat rpm 580
SHi
Cool rpm 600
Heat rpm 630
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-poles)
Input Power W –
Output Power W 40
Speed Hi
Cool rpm 840
Heat rpm 760
Moisture Removal L/h (Pt/h) 1.5 (3.2)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min) 6.7 (240)
Heat m
3
/min (ft
3
/min) 8.0 (280)
Lo
Cool m
3
/min (ft
3
/min) 7.3 (260)
Heat m
3
/min (ft
3
/min) 8.5 (300)
Me
Cool m
3
/min (ft
3
/min) 8.8 (310)
Heat m
3
/min (ft
3
/min) 9.7 (340)
Hi
Cool m
3
/min (ft
3
/min) 10.5 (370)
Heat m
3
/min (ft
3
/min) 10.8 (380)
SHi
Cool m
3
/min (ft
3
/min) 11.2 (400)
Heat m
3
/min (ft
3
/min) 11.7 (410)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min) 30.5 (1075)
Heat m
3
/min (ft
3
/min) 28.9 (1020)
Refrigeration
Cycle
Control Device Expansion Valve
Refrigerant Oil cm
3
FV50S (450)
Refrigerant Type g (oz) R410A, 1.13k (39.9)
Dimension
Height (I/D / O/D /
PANEL)
mm (inch) 260 (10-1/4) / 622 (24-1/2) / 51 (2-1/32)
Width (I/D / O/D /
PANEL)
mm (inch) 575 (22-21/32) / 824 (32-15/32) / 700 (27-9/16)
Depth (I/D / O/D /
PANEL)
mm (inch) 575 (22-21/32) / 299 (11-25/32) / 700 (27-9/16)
Weight
Net (I/D / O/D /
PANEL)
kg (lb) 18 (40) / 36 (79) / 2.5 (6)

Panasonic CS-E9PB4EA Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Product color	White
Gas hose diameter	9.52 mm
Liquid hose diameter	6.35 mm
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 43 °C
Operating temperature (heating) (T-T)	-10 - 24 °C
Indoor unit type	Ceiling
Indoor unit width	575 mm
Indoor unit height	260 mm
Indoor unit weight	18000 g
Indoor unit noise level (low speed)	23 dB
Indoor unit noise level (high speed)	35 dB
Outdoor unit noise level	- dB
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
